YSM40R_2-Beam_PartList - 第63页
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 90990-28J033 W ASHER,PLAIN 1 2 91312-04008 BOL T HEX,SOCKET HEAD 4 3 91312-04010 BOL T HEX,SOCKET HEAD 4 4 91312-05014 BOL T HEX,SOCKET HEAD 4 5 91312…
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 99480-04012 PIN,PARALLEL 2
2 95302-12600 NUT HEXAGON (P=1.25) 4
3 90440-10J050 CIRCLIP 2
4 91312-03008 BOLT HEX,SOCKET HEAD 4
5 91312-04006 BOLT HEX,SOCKET HEAD 4
6 91312-04008 BOLT HEX,SOCKET HEAD 13
7 91312-05012 BOLT HEX,SOCKET HEAD 4
8 91312-05030 BOLT HEX,SOCKET HEAD 4
9 91312-06012 BOLT HEX,SOCKET HEAD 2
10 91312-06020 BOLT HEX,SOCKET HEAD 4
11 KLF-M3T15-22 STAY,SIDE L 1
12 KLF-M3T15-32 STAY,SIDE R 1
13 KLF-M3T68-00 BRACKET 1
14 KLF-M3T68-10 BRACKET 1
15 KLF-M3T70-51 COVER,FR UPPER 1
16 KLF-M3T78-01 STAY,CLAMP L 1
17 KLF-M3T78-11 STAY,CLAMP R 1
18 KLF-M3T79-01 STAY,CONNECTOR 1
19 KLF-M3T99-00 SCREW,STEP 2
20 KLF-M3T91-00 BASE,CLAMP L 1
21 KLF-M3T91-50 BASE,CLAMP R 1
22 KLF-M3T92-00 LEVER,CLAMP 2
23 KLF-M3T93-00 PIN 2
24 KLF-M3T94-00 DOG,CLAMP L 1
25 KLF-M3T94-50 DOG,CLAMP R 1
26 KLF-M3T96-00 BLOCK 2
27 KLF-M3T97-01 HOOK 2
28 KLF-M3T98-01 PULL ACTION 2
29 KLF-M3T9A-00 CAM FOLLOWER 2
30 KLF-M3TB2-20 STAY,SLOPE L 1
31 KLF-M3TB2-30 STAY,SLOPE R 1
32 KLF-M3TJ1-00 BRKT.,HD CNT.1 1
33 KLF-M3TJ3-10 FRAME,PIN 1
34 KLF-M653R-00 SEN.CUT CLAMP ASSY 2
35 91312-06025 BOLT HEX,SOCKET HEAD 8
36 91312-08016 BOLT HEX,SOCKET HEAD 4
37 KLF-M3TS1-00 COVER,CONNECTOR 1
38 KLF-M3TS2-00 DUCT,CONNECTOR 1
39 KLF-M3TS3-00 DUCT COVER,CONNECTOR 1
40 91312-03006 91312-03006 3
5
10
RMV(Desorption) / Clamp
Tape Cutter
KMB-100-1607
33
6
10
34
32
18
2
13
2
14
6
6
6
6
6
7
5
9
35
35
5
35
9
7
36
35
19
29
3
27
22
23
1
19
36
27
3
24
6
1
34
4
26
16
29
22
23
20
8
25
4
21
8
26
28
28
35
35
11
12
15
17
31
30
37
39
38
5
5
5
40
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 90990-28J033 WASHER,PLAIN 1
2 91312-04008 BOLT HEX,SOCKET HEAD 4
3 91312-04010 BOLT HEX,SOCKET HEAD 4
4 91312-05014 BOLT HEX,SOCKET HEAD 4
5 91312-08030 BOLT HEX,SOCKET HEAD 4
6 91312-08035 BOLT HEX,SOCKET HEAD 6
7 92A08-04006 SCREW,SET 1
8 99480-06030 PIN,PARALLEL 1
9 KLF-M2659-00 STAY,CABLE Y 1
10 KLF-M3T52-S0 BLOCK,BASE SET 1
11 KLF-M3T58-00 BLOCK,STOPPER 1
12 KLF-M3T58-10 BLOCK,STOPPER 1
13 KLF-M3TFL-00 GUIDE,CTAT. L 1
14 KLF-M3TFM-00 GUIDE,CTAT. R 1
15 KLF-M3TFN-00 BRACKET CTG. 2
16 99480-08020 PIN,PARALLEL 4
17
90990-30J084 SHIM,CUTTER BASE0.02 1
90990-30J085 SHIM,CUTTER BASE0.05 1
90990-30J092 SHIM,CUTTER BASE0.1 1
6
10
RMV(Desorption) / R Base
Tape Cutter
KMB-100-1607
16
17
11
5
6
4
3
15
13
16
16
16
14
15
5
12
17
2
9
3
4
10
10
6
8
6
1
7
7
10
Cutter Carriage
1 (2-Beam)
Tape Cutter
KMB-100-1607
35
20
35
4
2
4
32
19
10
6
7
9
7
37
3
17
13
34
37
14
1
12
8
14
30
37
34
15
31
36
2
36
31
38
2
36
31
2
36
31
16
5
24
2
36
31
4
19
7
35
37
3
10
32
7
6
18
3
2
4
21
23
4
28
27
29
4
26
11
33
22
3
37
35
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 90172-00J040 WASHER, EXTL, TOOTHED 1
2 90172-00J050 WASHER, EXTL, TOOTHED 14
3 90172-00J060 WASHER, EXTL, TOOTHED 10
4 90990-12J001 SCREW, BIN. HEAD W/W 20
5 90990-12J004 SCREW, BIN. HEAD W/W 6
6 90990-28J047 WASHER,PLAIN 2
7 90990-31J006 BOLT, SHOULDER 4
8 91312-04006 BOLT HEX,SOCKET HEAD 1
9 91312-05008 BOLT HEX,SOCKET HEAD 4
10 KGS-M1348-00 GAS SPRING 2
11 90990-28J082 WASHER,PLAIN 1
12 KHY-M372C-10 CHAIN 1
13 KHY-M374C-00 CASTER 2
14 KLF-M1601-20 SMEMA CUTTER CAR. 4 No S.T.D
15 KLF-M3TE1-00 BASE,CT 1
16 KLF-M3TE2-00 RIB,CT R 1
17 KLF-M3TE3-00 FRAME,L 1
18 KLF-M3TE4-00 FRAME,R 1
19 KLF-M3TE7-00 STAY,GAS SPRING 2
20 KLF-M3TE8-00 COVER,BACK 1
21 KLF-M3TE9-00 COVER,MAIN 1
22 KLF-M3TEC-00 BRKT.,COVER 1
23 KLF-M3TEM-00 PULL,CT 2
24 KLF-M3TES-00 COVER,L SIDE 1
25 KLF-M3TET-00 COVER,R SIDE 1
26 KLF-M3TEK-00 HANDLE 1
27 KLF-M3TFB-00 SEAL,UP/DOWN 1
28 KLF-M3TFC-00 SEAL,1 PROCEDURE 1
29 KLF-M3TFD-00 SEAL,2 PROCEDURE 1
30 KM0-M3741-00 CASTER 63 2
31 91312-05010 BOLT HEX,SOCKET HEAD 14
32 91312-05018 BOLT HEX,SOCKET HEAD 4
33 91312-06014 BOLT HEX,SOCKET HEAD 6
34 91312-06060 BOLT HEX,SOCKET HEAD 16 S.T.D 91312-06008
35 92012-06010 BOLT BUTTON HEAD 4
36 92902-05200 WASHER,PLAIN 14
37 92902-06200 WASHER,PLAIN 26
38 KLF-M3TE2-50 RIB,CT L 1
