Assembly instructions Pass-through transpor t for SIPLACE HF-series / X-series / D3 04/2010 Edition 27 : Route the connecting cable thr ough the insi de of the machine to the pneumatic unit. Cable 2 2 : Pull the cable th…
Assembly instructions Pass-through transport for SIPLACE HF-series / X-series / D3
04/2010 Edition
26
: Route the long connecting cable as shown in the photograph.
2
Assembly instructions Pass-through transport for SIPLACE HF-series / X-series / D3
04/2010 Edition
27
: Route the connecting cable through the inside of the machine to the pneumatic unit.
Cable
2
2
: Pull the cable through the conveyor control housing.
Cable
Hole
2
2
Assembly instructions Pass-through transport for SIPLACE HF-series / X-series / D3
04/2010 Edition
28
: Screw the button to the hole on the front panel of the drawer. If there is no hole, then you will
have to drill one first (see top and bottom photograph).
Lock the button in place with the nuts provided
so that it is seated firmly.
Button
2
2
2
2
2
2
2
2
