Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

424 211FE370 BRACKET 1 2091401A0G-004

425 23N30498 ACCESS_WIRING 1

2091401A0G-005

426 23N10027 BRACKET_WIRING 2

2091401A0G-006

427 23N30610 ACCESS_WIRING 1

2091401A0G-007

428 23N30605 ACCESS_WIRING 1

2091401A0G-008

429 4S410005 THERMISTOR 2

2091401A0G-009

430 4J320201 TERMINAL 2

2091401A0G-010

431 23N30629 ACCESS_WIRING 2

2091401A0G-011

432 23N30114 ACCESS_WIRING 1

2091401A0G-012

433 4J320185 TERMINAL 2

2091401A0G-013

434 23N30609 ACCESS_WIRING 1

2091401A0G-014

435 4J200033 FUSE_HOLDER 2

2091401A0G-015

436 4S300024 FUSE_250V_5A 2

2091401A0G-016

437 23N30606 ACCESS_WIRING 1

2091401A0G-017

438 4S510019 TIMER 2

2091401A0G-018

439 4J120079 SOCKET 2

2091401A0G-019

440 23N10002 BRACKET_WIRING 2

2091401A0G-020

441 211DE329 PLATE 1

2091401A0G-021

445 221DA053 MACHINE_SCREW 2

2091401A0G-025

446 221HA005 WASHER 2

2091401A0G-026

447 221HA303 ROHS_WASHER 2

2091401A0G-027

448 221AA030 ROHS_HEX-SCT 2

2091401A0G-028

451 0914BA0J CORD 1

2091401A0G-501

452 0914BA0K CORD 1

2091401A0G-502

453 0914B907 TERMINAL 10

2091401A0G-503

454 23K10004 CASE_CONN 2

2091401A0G-504

455 4J300002 CAB_JOINTTERMIN 6

2091401A0G-505

456 23K10001 CASE_CONN 1

2091401A0G-506

457 4J300001 CAB_JOINTSLEEVE 2

2091401A0G-507

458 23N20103 TUBE_WIRING 21

2091401A0G-508

459 23N20115 TUBE_WIRING 10

2091401A0G-509

460 23N30737 ACCESS_WIRING(M 2

2091401A0G-510

Fig. D1

0912-002

Fig. D1-5

UNIT-3

Fig. D1

ELEC1

SIGMA-G4DA

SIGMA-G4DB

SIGMA-G4DC

MEMO

CONTENTS

Fig. D2 CPU

ボックス部

CPU BOX SECTION

Fig. D2-A

全体図

PARTS LAYOUT

Fig. D2-1

CPU 2

ボックス

CPU 2 Box

Fig. D2-2

CPU 1

ボックス

CPU 1 Box

0912-002

Fig. D2

UNIT-3

Fig. D2

CPU
