P-309-002e - 第270页
0912-002 See Fig. G1-1 Key No.51 495 496 494 495 496 488 495 496 490 450 431 447 430 A See Fig. G1-6 Key No.501 429 476 486 486 486 474 425 41 1 439 406 433 426 405 432 41 1 B C DET AIL C DET AIL B 476 421 466 421 428 44…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
302 4M150279 MOTOR_AC-SERVO 2 1091603300-002
303 4M150280 MOTOR_AC-SERVO 2 1091603300-003
312 0916D30Y BALL_SCREW 2 1091603300-012
314 223Q0769 PULLEY_TIMING 2 1091603300-014
315 223Q0711 PULLEY_TIMING 2 1091603300-015
316 223L0358 BELT_TIMING 2 1091603300-016
327 221AA011 ROHS:BOLT_HEX-SCT 4 1091603300-027
338 211G3396 BLOCK 2 1091603300-038
340 211D9619 PLATE 2 1091603300-040
341 211FE198 BRACKET 2 1091603300-041
342 211FE541 BRACKET 2 1091603300-042
343 210A3165 BASE 2 1091603300-043
352 0916D310 BEARING_UNIT 2 1091603300-052
353 216A1487 COLLAR 2 1091603300-053
354 222M1420 SPRING_COMP 2 1091603300-054
355 211G5191 BLOCK 2 1091603300-055
370 223C0238 COUPLING 2 1091603300-070
371 09163001 ASSY_SENSOR 2 1091603300-071
372 09163002 ASSY_SENSOR 2 1091603300-072
373 09163003 ASSY_SENSOR 2 1091603300-073
376 221AA121 ROHS:BOLT_HEX-SCT 4 1091603300-076
378 221A0245 BOLT_HEX-SCT 2 1091603300-078
379 221AA145 ROHS:BOLT_HEX-SCT 16 1091603300-079
380 221AA321 ROHS:BOLT_HEX-SCT 6 1091603300-080
381 221AA322 ROHS:BOLT_HEX-SCT 2 1091603300-081
382 221AA005 ROHS:BOLT_HEX-SCT 4 1091603300-082
383 221AA006 ROHS:BOLT_HEX-SCT 32 1091603300-083
384 221AA007 ROHS:BOLT_HEX-SCT 14 1091603300-084
385 221AA013 ROHS:BOLT_HEX-SCT 4 1091603300-085
387 221AA031 ROHS:BOLT_HEX-SCT 4 1091603300-087
391 221CA026 SET SCREW 4 1091603300-091
392 221FA003 NUT_HEX 2 1091603300-092
393 221FA005 NUT_HEX 4 1091603300-093
397 221HA001 WASHER 2 1091603300-097
399 221HA201 WASHER 2 1091603300-099
3A0 221HA002 WASHER 6 1091603300-100
3A1 221HA102 WASHER 6 1091603300-101
3A2 221HA003 WASHER 46 1091603300-102
3A3 221HA103 WASHER 46 1091603300-103
Fig. G1
0912-002
Fig. G1-4
UNIT-6
Fig. G1
HEAD 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
0912-002
See Fig. G1-1
Key No.51
495
496
494
495
496
488
495
496
490
450
431
447
430
A
See Fig. G1-6
Key No.501
429
476
486
486
486
474
425
411
439
406
433
426
405
432
411
B
C
DETAIL C
DETAIL B
476
421
466
421
428
444
4A2
4A1
445
DETAIL A
0916 3 31J
Fig. G1-5
ノズルシャフト、真空フィルタ
Nozzle Shaft, Vaccum Filter
Fig. G1
高速ヘッド部
HIGH SPEED HEAD SECTION
UNIT-6
Fig. G1
HEAD 1
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
405 23D10016 ACCESSORY_SV 30 1091603300-005
406 225B0572 AIR LINE EQPT 60 1091603300-006
411 222H0163 CAM FOLLOWER 30 1091603300-011
421 226A0279 SEAL 60 1091603300-021
425 221AA330 ROHS:BOLT_HEX-SCT 80 1091603300-025
426 226A0276 SEAL 60 1091603300-026
428 226A0286 SEAL 30 1091603300-028
429 213G0285 ROTOR 2 1091603300-029
430 213G0284 ROTOR 2 1091603300-030
431 211FE200 BRACKET 2 1091603300-031
432 0916D31G DISK 2 1091603300-032
433 216B1811 HOLDER 30 1091603300-033
439 211G6373 BLOCK 30 1091603300-039
444 0916D318 SPRING_COMP 30 1091603300-044
445 0916D31E SEAL 90 1091603300-045
447 0916D31F DISK 2 1091603300-047
450 211G5985 BLOCK 2 1091603300-050
466 216B1854 HOLDER 30 1091603300-066
474 221AA332 ROHS:BOLT_HEX-SCT 4 1091603300-074
476 221AA121 ROHS:BOLT_HEX-SCT 36 1091603300-076
486 221A0332 BOLT_HEX-SCT 16 1091603300-086
488 221AA205 BOLT_HEX-SCT 2 1091603300-088
490 221AA202 BOLT_HEX-SCT 8 1091603300-090
494 221AA206 BOLT_HEX-SCT 4 1091603300-094
495 221HA281 WASHER SPR 3 14 1091603300-095
496 221HA290 WASHER V 3X7X0.5 14 1091603300-096
4A1 0916D31H NOZZLE_SHAFT 2 309160331J-001
4A2 216B1861 HOLDER 2 309160331J-002
Fig. G1
0912-002
Fig. G1-5
UNIT-6
Fig. G1
HEAD 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
