Key No. P AR T No. P AR T NAME Q’ty REMARKS NOTE 5A7 221HA005 WASHER 8 1091603300-107 5A8 221HA105 WASHER 8 1091603300-108 5B1 0916D30X SHAFT 2 2091603301-001 5B2 23K10341 CASE_CONN 2 2091603301-002 5B3 23K10287 CASE_CON…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
501 4M150286 MOTOR_AC-SERVO 2 1091603300-001
504 225F0702 PIPE FITTINGS 2 1091603300-004
507 221C0080 SET SCREW 2 1091603300-007
508 225F0612 PIPE FITTINGS 2 1091603300-008
510 222L0987 GUIDE_LINEAR 2 1091603300-010
517 0916D30T COUPLING 2 1091603300-017
518 222D0425 BEARING_RADIAL 2 1091603300-018
519 222D0426 BEARING_RADIAL 2 1091603300-019
520 222D0430 BEARING_RADIAL 4 1091603300-020
522 226A0293 SEAL 4 1091603300-022
523 226A0190 SEAL 4 1091603300-023
524 09163006 ASSY_SENSOR 2 1091603300-024
535 216C1062 ROD 2 1091603300-035
536 211G5983 BLOCK 2 1091603300-036
537 0916D30P BLOCK 2 1091603300-037
546 211FD778 BRACKET 2 1091603300-046
548 223C0204 COUPLING 2 1091603300-048
549 211E1034 SPACER 4 1091603300-049
551 225F0427 PIPE FITTINGS 2 1091603300-051
556 221G0206 NUT 2 1091603300-056
557 216B1829 HOLDER 2 1091603300-057
558 222D0435 BEARING_RADIAL 2 1091603300-058
559 216A1614 COLLAR 2 1091603300-059
560 216C1009 ROD 2 1091603300-060
561 222M1444 SPRING_COMP 2 1091603300-061
562 221K0095 RING E 2 2 1091603300-062
563 216A1582 COLLAR 4 1091603300-063
564 222D0439 BEARING_RADIAL 2 1091603300-064
567 221H0266 WASHER 2 1091603300-067
568 211AC769 COVER 2 1091603300-068
569 211DE191 PLATE 4 1091603300-069
575 221AA333 ROHS:BOLT_HEX-SCT 6 1091603300-075
576 221AA121 ROHS:BOLT_HEX-SCT 6 1091603300-076
582 221AA005 ROHS:BOLT_HEX-SCT 4 1091603300-082
583 221AA006 ROHS:BOLT_HEX-SCT 16 1091603300-083
584 221AA007 ROHS:BOLT_HEX-SCT 8 1091603300-084
587 221AA031 ROHS:BOLT_HEX-SCT 8 1091603300-087
589 221DA003 MACHINE SCREW 4 1091603300-089
591 221CA026 SET SCREW 4 1091603300-091
597 221HA001 WASHER 16 1091603300-097
598 221HA101 WASHER 16 1091603300-098
5A2 221HA003 WASHER 28 1091603300-102
5A3 221HA103 WASHER 20 1091603300-103
5A4 221HA203 WASHER 8 1091603300-104
5A5 221HA115 WASHER 12 1091603300-105
0912-002
Fig. G1-6
Fig. G1
高速ヘッド部
HIGH SPEED HEAD SECTION
UNIT-6
Fig. G1
HEAD 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
5A7 221HA005 WASHER 8 1091603300-107
5A8 221HA105 WASHER 8 1091603300-108
5B1 0916D30X SHAFT 2 2091603301-001
5B2 23K10341 CASE_CONN 2 2091603301-002
5B3 23K10287 CASE_CONN 2 2091603301-003
5B4 4J300048 CABLE JOINT_TERMINAL 22 2091603301-004
5B5 23K10264 CASE_CONN 2 2091603301-005
5B6 4J300047 CABLE JOINT_TERMINAL 6 2091603301-006
5B7 23K00012 CONTACT PARTS_CONN 8 2091603301-007
5B8 0916D305 CORD 2 2091603301-008
5B9 0916D304 CORD 2 2091603301-009
5C0 0916D303 CORD 2 2091603301-010
5C1 0916D302 CORD 2 2091603301-011
5C2 0916D30E CORD 2 2091603301-012
5C3 0916D30F CORD 2 2091603301-013
5C4 0916D30A CORD 2 2091603301-014
5C5 0916D309 CORD 2 2091603301-015
5C6 0916D308 CORD 2 2091603301-016
5C7 0916D311 P.C.B,MOUNT 2 2091603301-017
5C8 0916D312 P_C_B_MOUNT 2 2091603301-018
5D0 23N20110 TUBE WIRING 18 2091603301-020
Fig. G1
0912-002
Fig. G1-6
UNIT-6
Fig. G1
HEAD 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
MEMO
