Fig. G2-2 ノズルストッカ駆動部 Nozzle Stocker Driving Section 0912-002 1 13 1 15 1 16 1 12 1 14 153 1 10 104 1 1 1 1 17 137 131 128 105 109 106 109 131 107 108 124 123 122 1 18 135 136 138 132 133 138 128 126 144 134 125 126 127 1…
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
1 0919I001 STOCKER_BLOCK 2 2091908000-001
2 211DE925 PLATE 2
2091908000-002
3 221J1002 SPRING_PIN 4
2091908000-003
4 222N0067 SPRING_TENSION 2
2091908000-004
5 226J1958 MECH PARTS(MAGNET) 2
2091908000-005
6 221DA002 MACHINE SCREW 2
2091908000-006
7 221FA001 NUT_HEX 2
2091908000-007
Fig. G2
0912-002
Fig. G2-1
UNIT-6
Fig. G2
STOCKER 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
Fig. G2-2
ノズルストッカ駆動部
Nozzle Stocker Driving Section
0912-002
1 13
1 15
1 16
112
114
153
1 10
104
1 1 1
1 17
137
131
128
105
109
106
109
131
107
108
124
123
122
1 18
135
136
138
132
133
138
128
126
144
134
125
126
127
132
120
121
1 1 9
129
130
131
Fig. G2
高速ノズルストッカ部
HIGH SPPED NOZZLE STOCKER SECTION
UNIT-6
Fig. G2
STOCKER 1
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
104 225F0261 PIPE FITTINGS 2 1091908012-004
105 212A2815 GUIDE 2
1091908012-005
106 216A1615 COLLAR 2
1091908012-006
107 216S3241 LEVER 2
1091908012-007
108 216D0603 PIN_HINGE 2
1091908012-008
109 222D0004 BEARING_RADIAL 4
1091908012-009
110 222N0019 SPRING_TENSION 2
1091908012-010
111 211F8213 BRACKET 2
1091908012-011
112 211F8214 BRACKET 2
1091908012-012
113 211D9588 PLATE 2
1091908012-013
114 222M0657 SPRING_COMP 2
1091908012-014
115 211G3505 BLOCK 2
1091908012-015
116 216S2914 LEVER 2
1091908012-016
117 213A1660 SHAFT 2
1091908012-017
118 221AA033 ROHS:BOLT_HEX-SCT 2
1091908012-018
119 221AA031 ROHS:BOLT_HEX-SCT 2
1091908012-019
120 221HA001 WASHER 8
1091908012-020
121 221HA101 WASHER 4
1091908012-021
122 221FA005 NUT_HEX 2
1091908012-022
123 221BA003 ROHS:BOLT_HEX 2
1091908012-023
124 221AA013 ROHS:BOLT_HEX-SCT 4
1091908012-024
125 221AA003 ROHS:BOLT_HEX-SCT 4
1091908012-025
126 221HA002 WASHER 4
1091908012-026
127 221HA102 WASHER 4
1091908012-027
128 221CA026 SET SCREW 4
1091908012-028
129 221AA006 ROHS:BOLT_HEX-SCT 4
1091908012-029
130 221HA003 WASHER 4
1091908012-030
131 221HA203 WASHER 8
1091908012-031
132 221DA003 MACHINE SCREW 6
1091908012-032
133 221FA001 NUT_HEX 2
1091908012-033
134 221AA001 ROHS:BOLT_HEX-SCT 4
1091908012-034
135 221KA003 ROHS:RING 4
1091908012-035
136 221FA003 NUT_HEX 2
1091908012-036
137 221AA005 ROHS:BOLT_HEX-SCT 4
1091908012-037
138 221AA008 ROHS:BOLT_HEX-SCT 4
1091908012-038
144 221HA201 WASHER 4
1091908012-044
153 09198100 ASSY_SENSOR 2
1091908012-053
Fig. G2
0912-002
Fig. G2-2
UNIT-6
Fig. G2
STOCKER 1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
