SIPLACE Software Guide SR.504.xx 3 Graphical user interface

Issue 01/03 EN 3.3 User interface - views and menus

Conveyor 1 F8 3

This is used to call the single functions for PCB conveyor 1 (= right conveyor track in the case of

dual conveyors). These are used to test and set the functional modules for PCB conveyor as well

as to set the conveyor width. 3

NOTE

The next two menu options belong to the group of vision functions.

These functions are used to teach and test fiducials, measure components and change compo-

nent package form data.

The vision functions cannot be executed at the "Operator" access level. 3

Teach fiducial F9 3

This menu item is used to call the functions for the processing of fiducials for PCB position recog-

nition.

For a more extensive description of the procedure refer to the "Vision functions" section of the op-

erating instructions and in the online Help system. 3

Test component F10 3

This menu item is used to call the functions for the processing of component package forms for

component centering.

For a more extensive description of the procedure refer to the "Vision Functions" section of the

operating instructions. 3

Start SITEST F11 3

This automatically starts the SITEST test program for machine set-up and calibration.

The user interface, together with the procedure for the execution of the functions, is described in

the separate User’s Manual for the SITEST test program. 3

NOTE

The SITEST test program cannot be started from the "Operator" access level. 3

3 Graphical user interface SIPLACE Software Guide SR.504.xx

3.3 User interface - views and menus Issue 01/03 EN

GEM F12 3

This menu item is used to call the GEM interface functions. See Option "GEM Interface" on page

77. 3

NOTE

The GEM interface functions cannot be called unless the interface has been configured.

At the "Operator" access level, only the function "Send and receive messages" is available. In the

"GEM State View" function the buttons are inactive for the "Operator". 3

SIPLACE Software Guide SR.504.xx 3 Graphical user interface

Issue 01/03 EN 3.3 User interface - views and menus

3.3.2.3 "Options" menu

The "Options" menu is only available in the main view. This menu contains all the supplementary

functions. 3

Å Click the required menu item and then make the appropriate settings or selections in the cor-

responding windows or dialog boxes.

Machine options... 3

Depending on access level, you can obtain information about the station configuration ("Opera-

tor") or activate or deactivate the displayed machine options ("Line engineer", "Service"). 3

Å Click the Machine options... menu item (or the appropriate button in the working area of the

main view). The following window is displayed.

Fig. 3.3 - 4 "Machine options - entire machine" dialog box (Example: HF)

NOTE

Only those machine options are displayed which are configured at the current station.

This dialog box may contain different information and check boxes depending on the type of

SIPLACE machine being used. 3
