7.4 Option "Component level indicator"
7.4.1 Purpose
This component informs the operator, at any time during placement operation when the individual
feeders are about to run out of components and need to be refilled. 7
Before a feeder becomes empty, a warning is output. If the operator reacts to this warning in time,
it is possible to avoid the machine coming to a standstill as a result of a "Track empty" error. 7
The operator can also be informed in time when a new component tape must be spliced, or a bulk
case or vibratory stick feeder must be refilled. 7
7
7.4.2 Description
NOTE
Please refer to the Component level indicator user manual and the online Help for a detailed
description of this option. 7
