1.3.3 Mounting plate

The turnable mounting plate allows maintenance and service work on all placement heads. The

placement heads are fixed with two mounting screws.

ATTENTION

Only use original mounting screws the installation..

fig. 1.3 - 3 Fixation on mounting plate

(1) Fixation of C&P20 / C&P20A (2) Fixation of CPP Head

(3) IC Head (4) Pick&Place module (Twin Head)

(5) Fixation of C&P6712 DLM2/3
