Inspection of the Contr oller 7-15 4 OUT4.3 RESERVED OUTPUT PORT 3 OUT4.4 RESERVED OUTPUT PORT CN12 4 OUT4.5 RESERVED OUTPUT PORT 6PIN CONNECTOR 3 OUT4.6 RESERVED OUTPUT PORT CN13 4 OUT4.7 RESERVED OUTPUT PORT 6PIN CONNE…
Samsung Component Placer CP45FV Series Maintenance Guide
PIN NO. DEF. DESCRIPTION REMARK
15 OUT2.4 BUZZER OUT
16 OUT2.5 FFEEDER CHANGE SW. LAMP OUT
21 OUT2.6 RESET SW. LAMP OUT
22 OUT2.7 RESERVED OUTPUT PORT
1 OUT3.0 RED LAMP OUTPUT
2 OUT3.1 BLUE LAMP OUTPUT
3 OUT3.2 GREEN LAMP OUTPUT
CN7
4 OUT3.3 YELLOW LAMP OUTPUT
6PIN CONNECTOR
1/3 OUT3.4 FRONT BELT CONTROL
CN8
2/4 OUT3.5 REAR BELT CONTROL
6PIN CONNECTOR
1/3 OUT3.6 Previous stage machine I/F OUT
CN9
2/4 OUT3.7 Next stage machine I/F OUT
6PIN CONNECTOR
3 IN6.0 FRONT FEEDER Unlock SENSOR
CN19
4 IN6.1 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN6.2 Previous stage machine I/F IN
CN20
4 IN6.3 Next stage machine I/F IN
6PIN CONNECTOR
3 IN7.0 RESERVED INPUT PORT
CN21
4 IN7.1 UPS IN POWER DROP INPUT
6PIN CONNECTOR
3 IN7.2 RESERVED INPUT PORT
CN22
4 IN7.3 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.4 RESERVED INPUT PORT
CN23
4 IN7.5 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.6 RESERVED INPUT PORT
CN24
4 IN7.7 RESERVED INPUT PORT
6PIN CONNECTOR
CN25 2 AN0 RESERVED ANALOG INPUT PORT 6PIN CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.4 FRONT_KEYPAD_USED
4 IN6.6 FRONT_KEYPAD_EMG
5 +12V +12V for JOGBOX
CN26
6 GND GROUND
FROM FRONT JOGBOX CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.5 REAR_KEYPAD_USED
4 IN6.7 REAR_KEYPAD_EMG
5 +12V +12V for JOGBOX
CN27
6 GND GROUND
FROM REAR JOGBOX CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
CN28
3 GND GROUND
TO MVME162 BOARD
OUTPUT
PIN NO. DEF. DESCRIPTION REMARK
3 OUT4.0 READY RELAY OUTPUT
CN10
4 OUT4.1 RESERVED OUTPUT PORT
6PIN CONNECTOR
CN11
3 OUT4.2 RFEEDER CHANGE SW. LAMP OUT
6PIN CONNECTOR
7-14
Inspection of the Controller
7-15
4 OUT4.3 RESERVED OUTPUT PORT
3 OUT4.4 RESERVED OUTPUT PORT
CN12
4 OUT4.5 RESERVED OUTPUT PORT
6PIN CONNECTOR
3 OUT4.6 RESERVED OUTPUT PORT
CN13
4 OUT4.7 RESERVED OUTPUT PORT
6PIN CONNECTOR
Samsung Component Placer CP45FV Series Maintenance Guide
LED information for board status diagnosis
LED ON DESCRIPTION REMARK LED ON DESCRIPTION REMARK
LED1 Can transmission LED65 ANC1 Shutter Open Sensor Input 2
LED2 Error Occurrence LED66 Stop Sw. Input Input 2
LED3 Receiving Can LED67 ANC 2 Shutter Close Sensor Input 2
LED4 CPU Operation LED68 Reset Sw. Input Input 2
LED5 IO RESET LED69 ANC2 Shutter Open Sensor Input 2
LED6 Board Output Power LED70 I/O Sw. Input Input 2
LED7 Board Operation Power LED71 Dummy Input Input 2
LED40 PCB Input Sensor Input 1 LED72 Front Feeder Unlock Sensor Input 3
LED41 BUT Up Sensor Input 1 LED73 RearEmergency Input/CN-IN5 Input 3
LED42 PCB Wait Sensor Input 1 LED74
Front Feeder Alarm for
replacement Sensor
Input 3
LED43 BUT Down Sensor Input 1 LED75 Rear Door Input Input 3
LED44 Wait Stopper Up Sensor Input 1 LED76 Previous stage machine I/F In Input 3
LED45 Hole Fixer Right Sensor Input 1 LED77 RFeeder Change Sw. Input Input 3
LED46 Wait Stopper Down Sensor Input 1 LED78 Next stage machine I/F In Input 3
LED47 Hole Fixer Left Sensor Input 1 LED79 Rear Feeder Unlock Sensor Input 3
LED48 PCB Place Sensor Input 1 LED80 Front_Key_Pad_Used Input 3
LED49 Edge Pusher Forward Sensor Input 1 LED81
Rear Feeder Alarm for
replacement Sensor
Input 3
LED50 Place Stopper Up Sensor Input 1 LED82 Rear_Key_Pad_Used Input 3
LED51 Edge Pusher Backward Sensor Input 1 LED83
Main Pneumatic pressure
measurement Sensor Input 3
LED52 Place Stopper Down Sensor Input 1 LED84 Front Key Pad Emg. Input 3
LED53 Back Pusher Sensor Input 1 LED85 Pressure Sensor Enable Input 3
LED54 Dummy Input Input 1 LED86 Rear Key Pad Emg. Input 3
LED55 Back Pusher Sensor Input 1 LED87 Dummy Input Input 3
LED56 Front Emergency Input Input 2 LED88 I/O Power Drop Input Input 4
LED57 PCB Out Sensor Input 2 LED89 USP In Power Drop Input Input 4
LED58 Front Door Input Input 2 LED90 220V Main Power Drop Input Input 4
LED59 Out Stopper Up Sensor Input 2 LED91 110V Main Power Drop Input Input 4
LED60 Feeder Change Sw. Input Input 2 LED92 220V Sub Power Drop Input Input 4
LED61 Out Stopper Down Sensor Input 2 LED93 110V Sub Power Drop Input Input 4
LED62 Ready Sw. Input Input 2 LED94 Drmmy Input Input 4
LED63 ANC1 Shutter Close Sensor Input 2 LED95 Drmmy Input Input 4
LED64 Start Sw. Input Input 2
7-16
