KY8030-2XDL(2P) Part List - 第104页
No. Item Code No. Specific ati on De scription Typ e Q’TY Remark 1 5550 14-000003 4S56Q-0255 4S STEPPING MOTOR Part 1 2 V080-5 20015-A 8030 PULLEY MOTO R BKT Part 1 3 V040-5 22003-A BUFFER RIN G PULLEY 1 Part 1 4.5 . 1.7…
4.5.1.7 MOTOR UNIT 3
1
2
3
103
No. Item Code No. Specification Description Type Q’TY Remark
1 555014-000003 4S56Q-02554S STEPPING MOTOR Part 1
2 V080-520015-A 8030 PULLEY MOTOR BKT Part 1
3 V040-522003-A BUFFER RING PULLEY 1 Part 1
4.5.1.7 MOTOR UNIT 3
104
4.5.2 LEFT DISTRIBUTION MODULE
1
2
3
4
5
6
7
105
