No. Item Code No. Specifica t ion Description Type Q’TY Rem ark 20 5521 12-0000 02 280-315 (2:2 Oran. & Grey) Termi nal Block Ele ct ric 7 Te rminal ASS’Y 21 5516 14-0000 01 AZ17-11ZK-B1 Intelock S/W Ele ct ric 2 DOO…
No. Item Code No. Specification Description Type Q’TY Remark
1 552111-000001 30A-3P Terminal Block(Main Power) Electric 1 TERMINAL BLOCK
2 551615-000001 TO-2-1/EA/SVB Main Switch Electric 1 MAIN POWER S/W
3 551711-000001 MBS-1220-22 Noise Filter Electric 2 NF1, NF2
4 551918-000005 SG53C MCCB Electric 1 MCCB
5 552012-000005 FAZ-C10/2 CP Electric 1 CP2
6 552012-000006 FAZ-C16/2 CP Electric 1 CP1
7 551612-000004 M22-WRS/KW40(1a*6EA) KEY SWITCH Electric 1 RUN S/W
8 551919-000002 DILM12-10(24DC) MC Electric 1 MC3
9 551919-000004 DILM12-10 MC Electric 1 MC2
10 551919-000005 DILM17-10 MC Electric 1 MC1
11 551913-000003 ETS4-VS3 Power Relay Electric 1 RL1
12 552612-000005 SWS50-05V SMPS Electric 1 PS1
13 552612-000006 SWS150-24V SMPS Electric 3 PS2-1, PS2-2, PS3
14 552112-000001 249-116 (End Stop) Terminal Block Electric 2 Terminal ASS’Y
15 552112-000003 280-402 (2P Jumper) Terminal Block Electric 12 Terminal ASS’Y
16 552112-000004 280-833 (2:2 Grey) Terminal Block Electric 10 T/B01, T/B04
17 552112-000005 280-834 (2:2 Blue) Terminal Block Electric 4
T/B02, T/B05, T/B10
18 552112-000006 280-835 (2:2 Orange) Terminal Block Electric 10 T/B03, T/B07
19 552112-000007 280-837 (2:2 Ground) Terminal Block Electric 4 T/B FG
1. 2. POWER UNI LISTT PART
6
No. Item Code No. Specification Description Type Q’TY Remark
20 552112-000002 280-315 (2:2 Oran. & Grey) Terminal Block Electric 7 Terminal ASS’Y
21 551614-000001 AZ17-11ZK-B1 Intelock S/W Electric 2 DOOR LOCK S/W
22 551613-000001 M22-PV/K11 (Lable:60mm) EMERGENCY SWITCH Electric 2 EMERGENCY S/W
23 551612-000001 M22-WRLK-Y(2a+1b+LED) Conveyor SWITCH Electric 1 CONVEYOR S/W
24 552214-000001 TN32-2(WHT/GRN) Indictator Lamp Electric 1
INDICATOR LAMP
25 552511-000002 DP201A2123HBT-120X120X38 FAN Electric 3
FAN1, FNA2
26 552590-000001 FILTER 120X120 FAN FILTER Electric 3
27 E019-0111000 Main Power Cable Cable 1
28 E019-0121100 Fan Power Cable Cable 3
29 E019-0121200 Fan Power Connector Cable 3
7
