1.2.2 . ELECT RIC DOOR 22 2 3 4 5 1 6 7 8 9
No. Item Code No. Specification Description Type Q’TY Remark
1 552012-000006 FAZ-C16/2 CIRCUIT PROTECTOR Part 1 CP1
2 552012-000005 FAZ-C10/2 CIRCUIT PROTECTOR Part 1 CP2
3 551919-000005 DILM17-10 MAGNETIC CONTACTOR Part 1 MC1
4 551919-000002 DILM12-10(24DC) MAGNETIC CONTACTOR Part 1 MC2
5 551913-000003 ETS-VS3 POWER RELAY Part 1 RL1
6 551919-000002 DIL12-10 MAGNETIC CONTACTOR Part 1 MC3
7 552112-000004 280-833 (2:2 GREY) TERMINAL BLOCK Part 10 TB1, TB4
8 552112-000005 280-834 (2:2 BLUE) TERMINAL BLOCK Part 4 TB2, TB5
9 552112-000006 280-835 (2:2 ORANGE) TERMINAL BLOCK Part 8 TB3, TB7
10 552112-000007 280-837 (2:2 GROUND) TERMINAL BLOCK Part 4 GND
1.2.1.1. MC CP TB
21
1.2.2. ELECTRIC DOOR
22
2
3
4
5
1
6
7
8
9
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-122002-A ELECTRIC FRONT DOOR Part 1
2 A010-D12002-A VPC B/D COVER Part 1
3 501014-000030 VPC Board(V5.6A) PZT Control Board Part 1
4 V080-N12003-D BOARD BRACKET Part 1
5 609022-000004 HINGE 32-20 HINGE Part 2
6 609021-000002 PULL (75mm) HANDLE Part 1
7 501015-000005 STMC I/F Board(V5.3) Step Motor Controller Board(Dual) Part 2
8 551612-000001 M22-WRLK-Y(2a+1b+LED) CONVEYOR SWITCH Part 1
9 V080-N12004-B ELECTRIC FRONT COVER Part 1
1.2.2. ELECTRIC DOOR
