2.1 X FRAME BASE 28 7 6 1 2 3 4 5 8 9 11 10 13 12
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-200001 X FRAME BASE Assembly 1 2.1
2 V080-210101-D X AXIS SHOE Part 1
3 P021-920-004 Z-AXIS FIX PLATE Part 1
4 P021-900-000-1 Z AXIS PLATE Assembly 1 2.2
5 P021-900-000-2 Z AXIS MOTOR Assembly 1 2.3
6 V085-220002-A X AXIS COVER Part 1
7 V085-220003-A CONNECTOR BKT Part 1
8 V085-220001-A X CAFLUX BKT Part 1
9 V080-L22001-B X CAFLUX GUIDE Part 1
10 V080-210002-A X CAFLEX BRKT L Part 1
11 V080-210003-A X CAFLEX BRKT R Part 1
12 602911-000014 B15.050.048.0 L518.5(17) CAFLUX Part 1
13 602912-000005 1050.12PZ CAFLUX BKT Part 1
14 V085-310004-A X CAFLUX FIX PLATE Part 1
15 V085-320002-A Y CABLE COVER Part 1
2. X GANTRY UNIT
27
2.1 X FRAME BASE
28
7
6
1
2
3
4
5
8
9
11
10
13
12
No. Item Code No. Specification Description Type Q’TY Remark
1 V080-L21001-A X FRAME Part 1
2 554011-000005 PM-Y44 SENSOR Part 2
3 V080-L21002-A X FRAME SUPPORT BAR Part 2
4 606011-000047 HSR15R-2UUC1+700LP-II X MAIN LM GUIDE Part 1
5 V080-S00001-A X Y FIX SUPPORT UNIT Part 1
6 V080-S00002-A X Y SUPPORT UNIT
7 V085-310005-A GANTRY STOPPER Part 2
8 601611-000030 BNK1520-3GO+720LC5Y X BALL SCREW (X AXIS) Part 1
9 602611-000012 SDWA-42C-10-14 COUPLING Part 1
10 V080-L21004-A MOTOR BRKT Part 1
11 555013-000013 R2AA06020FXH00(200W) SERVO MOTOR Part 1
12 609021-000005 CG 6 HANDLE Part 1
13 606011-000048 HSR15R-1UUC1+700LP-II X SUPPORT LM GUIDE Part 1
2.1 X FRAME BASE
29
