3 Y GANTRY U NI T 34 1 2 3 4 5 6 7 8 9 10 11 15 13 14 C A B 12 B 21 22 C 23 25 26 24 A 16 17 18 19 20
No. Item Code No. Specification Description Type Q’TY Remark
1 555013-000012 SERVO MOTOR (Z AXIS) Part 1
2 P021-910-002-A MOTOR BKT Part 1
3 602611-000006 SDWA-26C-6-8 COUPLING Part 1
4 609039-000010 EK8-T2 SUPPORT UNIT Part 1
5 601611-000028 SR1002+93LC7 BALL SCREW (Z AXIS) Part 1
6 P021-910-001-A SUPPORT Part 1
7 P021-900-003-A SENSOR DOG Part 1
2.3 Z AXIS MOTOR
33
3 Y GANTRY UNIT
34
1
2
3
4
5
6
7
8
9
10
11
15
13
14
C
A
B
12
B
21
22
C
23
25
26
24
A
16
17
18
19
20
No. Item Code No. Specification Description Type Q’TY Remark
1 V080-L31002-A Y FRAME SUPPORT L Part 2
2 V080-L31001-A Y FRAME SUPPORT R Part 2
3 606011-000083 HSR15R-2UUC1+1000LP-II LM GUIDE (Y Axis) Part 2
4 V085-310001-A Y FRAME R Part 1
5 601611-000055 BNK1520-3GO+971LC5Y BALL SCREW (Y Axis) Part 1
6 V085-320001-A 8030 Y CAFLUX BKT Part 1
7 V080-320007-A Y CONNECTOR BKT Part 1
8 V085-320003-A Y CAFLUX COVER Part 1
9 602911-000042 255.07.055.0 (link:42) CAFLUX Part 1
10 606011-000112 HSR15R-2UU+940LP-I LM GUIDE (Y Axis) Part 1
11 V080-310008-B X LM GUIDE BLOCK L Part 1
12 V085-310002-A Y FRAME L Part 1
13 V080-310007-B Y AXIS SHOE Part 1
14 V085-320004-A AXIS SENSOR DOG Part 1
15 554011-000005 PM-Y44 PHOTO SENSOR Part 2
16 V085-310005-A GANTRY STOPPER Part 2
17 V080-S00001-A X Y FIX SUPPORT UNIT Part 1
18 602611-000013 SDWA-54C-10-16 COUPLING Part 1
3 Y GANTRY UNIT
35
