KY8030-2XDL(2P) Part List - 第43页
43 4.1.1 LEFT LM FIX BKT 1 2 2
No. Item Code No. Specification Description Type Q’TY Remark
17 602415-000019 SMALL 3D FRANGE ROLLER ROLLER Part 11
18 602415-000016 ESD D FLANGE BELT ROLLER ROLLER Part 4
19 602013-000038 D3-L2100 RING BELT Part 1
20 A010-D52002 UP/DOWN RAIL Assembly 1 4.1.6
21 A010-620002 WORK SENSOR Assembly 1 4.1.7
22 A010-520016-A SMALL BELT GUIDE Part 2
23 A010-520009 SENSOR Assembly 1 4.1.8
24 A010-520010 SENSOR Assembly 1 4.1.9
25 706012-000001 M-5ALHU-4 FITTING Part 4
4.1 FIRST FIX RAIL (REAR)
43
4.1.1 LEFT LM FIX BKT
1
2
2
No. Item Code No. Specification Description Type Q’TY Remark
1 V080-510007-B HEIGHT LM BKT Part 1
2 606011-000027 MGN12C-1-R46-Z0-C MINIATURE LM Part 2
4.1.1 LEFT LM FIX BKT
