KY8030-2XDL(2P) Part List - 第78页
No. Item Code No. Spe cification Description Type Q’ TY Remark 1 A010-D5 1007 -A RING B E LT RAIL Part 1 2 A010-D5 1016 -A INLET CYLINDER BLOCK Part 1 3 6090 37-000007 URETHANE STOPP ER STOPPER Part 2 4 A010-D5 1017 -A I…
4.3.1 UP/DOWN RAIL 3
1
2
3
4
5
7
6
8
77
No. Item Code No. Specification Description Type Q’TY Remark
1 A010-D51007-A RING BELT RAIL Part 1
2 A010-D51016-A INLET CYLINDER BLOCK Part 1
3 609037-000007 URETHANE STOPPER STOPPER Part 2
4 A010-D51017-A INLET CYLINDER JOINT Part 1
5 A010-D51018-A INLET CYLINDER HOUSING Part 1
6 706012-000003 M-5AU-4 FITTING Part 2
7 701011-000014 CQ2A-16-10D CYLINDER Part 1
8 A010-D52013-A SENSOR DOG 2 Part 1
4.2.1 UP/DOWN RAIL 3
78
79
4.4 FOURTH MOVINF RAIL (FRONT)
2
4
10
9
1
3
5
6
7
8
11
12
13
14
15
