KY8030-2XDL(2P) Part List - 第82页
No. Item Code No. Spe cification Description Type Q’ TY Remark 16 A0 10-D51021 -A LM GUIDE BLOCK Part 2 17 A0 10-D52002 UP/DOWN RAIL Assembly 1 4.1.6 18 A0 10-620004 TENSIONER Assembly 1 4.1.5 19 A0 10-520002 LEFT LM FIX…
4.4 FOURTH MOVINF RAIL (REAR)
20
16
17
18
19
21
22
23
24
25
81
No. Item Code No. Specification Description Type Q’TY Remark
16 A010-D51021-A LM GUIDE BLOCK Part 2
17 A010-D52002 UP/DOWN RAIL Assembly 1 4.1.6
18 A010-620004 TENSIONER Assembly 1 4.1.5
19 A010-520002 LEFT LM FIX BKT Assembly 2 4.1.1
20 A010-520003 RIGHT LM FIX BKT Assembly 1 4.1.2
21 554011-000005 PM-Y44 PHOTO SENSOR Part 1
22 V085-520011-A LANE 2 CAFLUX BKT Part 1
23 A010-D52018-A CONNECTER BKT 3 Part 1
24 A010-D52017-A CONNECTER BKT 2 Part 1
25 V085-510009-A WORK GUIDE RAIL Part 1
4.4 FOURTH MOVINF RAIL (REAR)
82
4.4.1 STOPPER 2
1
3
4
5
6
7
8
9
2
83
