4.5.1 .1 MO T OR UNIT 1 1 2 3 4 91
4.5.1 MOTOR BKT (BACK)
No. Item Code No. Specification Description Type Q’TY Remark
7 V085-520007-A REAR CABLE GUIDE Part 1
8 V085-520009-A CAFLUX BKT L Part 2
9 V080-500007 MANIFOLD ASSEMBLY Assembly 2 4.5.1.4
10 602012-000005 B060 S3M 225 DL TIMING BELT Part 3
11 602012-000006 B060 S3M 195 DL TIMING BELT Part 2
12 A010-D51002 MOTOR UNIT 1 Assembly 1 4.5.1.5
13 A010-510002 MOTOR UNIT 2 Assembly 2 4.5.1.6
14 A010-510003 MOTOR UNIT 3 Assembly 2 4.5.1.7
90
4.5.1.1 MOTOR UNIT 1
1
2
3
4
91
4.5.1.1 MOTOR UNIT 1
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-510010-A SYNC BAR Part 1
2 602411-000003 628ZZ BALL BEARING Part 2
3 A010-510014-A BELT ROLLER Part 1
4 V040-522002-C BUFFER RING PULLEY 2 Part 1
92
