4.5.1 .2 MO T OR UNIT 2 1 2 3 4 5 93
4.5.1.1 MOTOR UNIT 1
No. Item Code No. Specification Description Type Q’TY Remark
1 V085-510010-A SYNC BAR Part 1
2 602411-000003 628ZZ BALL BEARING Part 2
3 A010-510014-A BELT ROLLER Part 1
4 V040-522002-C BUFFER RING PULLEY 2 Part 1
92
4.5.1.2 MOTOR UNIT 2
1
2
3
4
5
93
4.5.1.2 MOTOR UNIT 2
No. Item Code No. Specification Description Type Q’TY Remark
1 601611-000071 SFSR1610D-X885-C7-D-RD BALL SCERW Part 1
2 602411-000001 6000ZZ BALL BEARING Part 2
3 601613-000001 RN10 LOCK NUT Part 1
4 V080-520010-B 6000ZZ BEARING COVER Part 1
5 V080-510040-B 8030 SCREW PULLEY Part 1
