8 4. Marker Pen Unit Section (Option) 4-1. Marker Pen Unit (Option) No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati. 1 LE1-M5101-03 BASE,GUIDE 1 2 LE1-M5102-02 HOLDER,PEN 1 3 LE1-M5103-01 STOP…
7
4. Marker Pen Unit Section (Option)
4-1. Marker Pen Unit (Option)
21
21
16
16
10
10
21
21
4
20
7
11
3
21
2
22
17
9
8
18
6
1
5
20
19
18
14
20
13
12
15
21
21
16
16
10
10
21
21
4
20
7
11
3
21
2
22
22
17
9
8
18
6
1
5
20
19
18
14
20
13
12
15
8
4. Marker Pen Unit Section (Option)
4-1. Marker Pen Unit (Option)
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M5101-03 BASE,GUIDE 1
2 LE1-M5102-02 HOLDER,PEN 1
3 LE1-M5103-01 STOPPER,PEN 1
4 LE1-M5104-02 HOOK 1
5 LE1-M5105-02 HOOK 1
6 LE1-M5106-01 PLATE,SENSOR 1
7 LE1-M5107-00 ADAPTER 1
8 LE1-M5111-02 PLATE 1
9 LE1-M5113-01 PLATE 1
10 LE1-M51A1-00 GUIDE 2
11 LE1-M51A2-00 KNOB 1
12
LE1-M51A3-00 PIN,HINGE
1
13 LE1-M51A4-00 SPRING 1
14 LC2-M912T-00 STOPPER 1
15 LE1-M50H7-00 LINER MOTOR 1
16 LC2-M654R-00 SENSOR. 2
17 LC7-M71G5-10 BOLT HEX.SO.LO HEAD 2
18 92D11-2F005 BOLT HEX. SOCKET HEAD 4
19 LG0-M71FP-50 WASHER PLAIN(S) 6
20 91317-03006 BOLT HEX. SOCKET HEAD 10 M3X6
21 91317-03008 BOLT HEX. SOCKET HEAD 18 M3X8
22 91317-04010 BOLT HEX. SOCKET HEAD 4 M4X10
9
5. Operation Box Section (Option)
5-1. Operation Box (Option)
3
4
5
6
7
1
2
8
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 LE1-M5602-00 UY CASE ADD 1
2 LE1-M5603-00 LABEL 1
3 LE1-M66JT-10 HNS.OK.SW.ASSY CE 1
4 LE1-M66JU-10 HNS.NG.SW.ASSY CE 1
5 LE1-M66JV-10 HNS.EXE.SW.ASSY CE 1
6 LE1-M66JW-10 HNS.STP.SW.ASSY CE 1
7 LE1-M66NE-00 HNS.X312-X313 1
8 LE1-M66NA-01 HNS.X201-X312 1 1.5m
