4 Setting up and commissioning User manual SIPLACE E 4.2 Infrastructure at the installation location From software ve rsion SC 708.0 05/2015 Edition 180 – F5: Safety contactors supply (24V) – F6: Power fail signal (24 V)…
User manual SIPLACE E 4 Setting up and commissioning
From software version SC 708.0 05/2015 Edition 4.2 Infrastructure at the installation location
179
Overview of the fuses 4
4
Fig. 4.2 - 6 Overview of the fuses
– F1: not used
– F2: PC1 supply (24 V)
– F3: Conveyor supply (24V)
– F4: Safety Relays supply (24 V)
F1 F2 F3 F4 F5
F6
F7
F8
F9
F10
F11
F12
F13
4 Setting up and commissioning User manual SIPLACE E
4.2 Infrastructure at the installation location From software version SC 708.0 05/2015 Edition
180
– F5: Safety contactors supply (24V)
– F6: Power fail signal (24 V)
– F7: MGCU supply (24V)
– F8: Distributor supply (24 V)
– F9: FCU1 supply (24V)
– F10: FCU 2 supply (24V)
– F11: Vision flash voltage (42 V)
– F12: Head drives supply(42V)
– F13: Conveyor supply (42V)
User manual SIPLACE E 4 Setting up and commissioning
From software version SC 708.0 05/2015 Edition 4.3 Setting up the machine
181
4.3 Setting up the machine
4.3.1 Warning instructions
4
4
4
4
4
WARNING
Observe the applicable accident prevention regulations!
Only SIPLACE engineers or qualified people are permitted to set up and commission the
machine.
The applicable accident prevention regulations concerning the transportation of
heavy goods must be followed.
WARNING
Risk of injury during assembly work to the underside of the machine!
There is a risk of injury during assembly work to the underside of the machine!
Secure the machine using suitable measures. The pallet jack must not be used as
the only support.
WARNING
Risk of injury during assembly work!
Incorrect positioning of gantries during assembly restricts the head clearance and can
lead to injuries.
Take care that the gantry is positioned over the board conveyor area.
WARNING
Height adjustment of machine!
Two people will be needed to adjust the height of the machine:
– One person completes the required assembly work
– The other person watches the stability of the raised machine during assembly.
WARNING
DANGER OF CRUSHING!
Risk of crushing feet when transporting the machine.
Wear specially reinforced shoes.
