5 Working with the machine User manual SIPLACE E
5.13 Changing the setup From software version SC 708.0 05/2015 Edition
242
5.13 Changing the setup
5.13.1 Printing out the setup list
Print out the setup list on the printer for the SIPLACE Station Programming. Go to Job Editor =>
Edit job => Optimizer => Actions => Export setup list.
5.13.2 What you should note when changing the feeder modules
Handle the feeder modules carefully when you insert them into or remove them from the
changeover table. Make sure that the SIPLACE SmartFeeder E do not bump against the cen
-
tering bar (see item 5 in fig. 5.11 - 3, page 233) of the changeover table.
Vacuum the supporting surfaces of the feeder modules and clean the surface of the change
-
over table when necessary.
5
Remove loose components using a brush or a vacuum cleaner with a suitable nozzle.
5
CAUTION
Risk of injuries!
Fine metal splinters from components could injure hands.
Avoid removing components from the changeover table with your fingers.
User manual SIPLACE E 5 Working with the machine
From software version SC 708.0 05/2015 Edition 5.14 Avoiding track errors
243
5.14 Avoiding track errors
5.14.1 General
Make sure that the areas around the feeder modules are clean and that there are no loose
components in the feeder area or under the feeder modules.
Refill promptly with components.
Splice the tapes early. This generally means that you are to prepare the splicing material
when there is still approximately 1.5 m of tape on the reel.
Handle the feeder modules carefully when you insert them into or remove them from the
changeover table as these are high-precision devices.
For SIPLACE SmartFeeder E, lower the pickup window since it can easily be damaged when
raised.
5
Check that the pick-up position is set correctly for the components on the feeder modules.
5.14.2 Avoiding track errors with the tape container
Insert the separating plates correctly (see fig. 5.10 - 2, page 228).
PLEASE NOTE
A raised pick-up window leads to noticeably impaired pick-up quality.
5 Working with the machine User manual SIPLACE E
5.14 Avoiding track errors From software version SC 708.0 05/2015 Edition
244
5.14.3 Component coordinate system and pickup angle
5
Fig. 5.14 - 1 Position of the component and its pick-up angle
Special
component
Stick
magazine:
Chip-
components
with polarity
0402
2220
The anode must be
aligned with the +X
coordinate.
Package form 0° coordinate system
Position in the feeder module
Pickup angle/
nozzle angle
Tape:
SOT 23
Stick
magazine:
Tape:
Tape:
SO-IC
DIL-IC
SOT 194
Tape:
Holes
Y
X
Y
X
Y
X
Y
X
Y
X
90°
90°
0°
90°
-90°
0°
