1.7 Important notes on the user manual
1.7.1 Contents and filing of the user manual
This user manual contains basic information that must be observed when setting up, operating
and maintaining the machine. The service engineers, qualified staff, operators and users plus sys
-
tem owner must therefore read it before commencing installation and commissioning.The instruc
-
tions must be kept permanently accessible where the machine is used.
In addition, the user must ensure that the employees have fully understood the contents of the
user manual.
1.7.2 Danger notes
1
1.7.3 Manufacturer's/supplier's liability
We hereby confirm that the contents of this user manual are of a descriptive and explanatory na
-
ture only and do not contain any contractual conditions or guaranties. The liability and obligations
assumed by ASM Assembly Systems Singapore Pte ltd can be found exclusively in the relevant
contract agreement concerning the supply of the machine described in this manual. This applies
in particular to all statements regarding performance or service life and the agreed liability for
faults or defects. The provisions of the contract regarding the liability for faults or defect are neither
extended nor restricted by any statements in this user manual.
WARNING
Read the user manual!
Only perform tasks on the machine if you have precise knowledge of the relevant sec
-
tion in the user manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this user manual through carefully.
1 Introduction User manual SIPLACE E
1.7 Important notes on the user manual From software version SC 708.0 05/2015 Edition
32
1.7.4 Revision table
1
1.7.5 Further information about and contents of the documentation package
1.7.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems Singapore Pte ltd
2 Corporation Road
#01-03 Corporation Place 1
1.7.5.2 SIPLACE E on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log onto our SIPLACE E home page
at http://www.e-by-siplace.com.
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
Edition Amendments
05/2015 EN First Edition with SC.708.0
User manual SIPLACE E 1 Introduction
From software version SC 708.0 05/2015 Edition 1.7 Important notes on the user manual
33
1.7.6 Abbreviations
1
A-Placement Alternating Placement
PA Placement area
CO Component
CP14 SIPLACE CP14, Collect&Place head with 14 segments
CP12 SIPLACE CP12, Collect&Place head with 12 segments
CP6 SIPLACE CP6, Collect&Place head with 6 segments
DCA Direct chip attach
ESD Electrostatically-sensitive group of components
EMC Electromagnetic compatibility
ESD Electrostatic sensitive device
SC Single conveyor
FC Flip chip
GCU Gantry control unit
GND Ground
MHCU Machine/Head control unit
HMI Human machine interface (Operator panel)
JTF-MW JEDEC Tray Feeder (Automatic tray changer)
LBO Long Board Option
PCB Printed circuit board
MCS Machine capability study
P&P1 Pick&Place module 1 of the SIPLACE TH
P&P2 Pick&Place module 2 of the SIPLACE TH
NC Nozzle changer
SMD Surface mounted device
SC Station computer
TH SIPLACE TH, Twin Pick&Place head
PP SIPLACE PP, Pick&Place head
VS Vision system
