2 Operational safety User manual SIPLACE E 2.2 Warning labels From software version SC 708.0 05/2015 Editio n 64 2.2.8 Warning label on PCB conveyor 2 Fig. 2.2 - 15 Warning labels on the PCB conveyor In fig. 2.2 - 15 , p…
User manual SIPLACE E 2 Operational safety
From software version SC 708.0 05/2015 Edition 2.2 Warning labels
63
2
High temperatures label in 2.2 - 14, page 62, item no. 03113901-01
2
Item no. 03009351-01
W211 in fig. 2.2 - 14, page 62, item no. 03009351-01.
2
RISK OF BURNS FROM HIGH TEMPERATURES!
The cover of the safety contactors can become hot during continuous oper
-
ation.
Take care when touching the cover.
2
2
MAIN POWER VOLTAGE!
Switch off the main power switch and wait 30 seconds until the capac
-
itors have discharged.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
2 Operational safety User manual SIPLACE E
2.2 Warning labels From software version SC 708.0 05/2015 Edition
64
2.2.8 Warning label on PCB conveyor
2
Fig. 2.2 - 15 Warning labels on the PCB conveyor
In fig. 2.2 - 15, page 64, hot surface label, item no. 03031926-01
W-Hot surface
2
RISK OF BURNS FROM HOT SURFACE!
The stopper units can become high temperatures continuous operation.
Take care when touching the stopper units.
User manual SIPLACE E 2 Operational safety
From software version SC 708.0 05/2015 Edition 2.2 Warning labels
65
2.2.8.1 Warning label "Sensitive conveyor sides"
2
Item no. 03110412-01 (1 on each conveyor side and placement area)
Sensitive conveyor sides!
The conveyor sides are highly sensitive and may not be moved
unless the brakes have been released.
Moving the sides without releasing the brakes can cause irrepa
-
rable damage to the conveyor sides.
