3-56 3 Periodic maintenance items 5.8 Air / mist filter 5.8.1 Cleaning the filter and cup Airfiltersandoilmistfiltersareinstalledtopreventoil,w ater ,andimpurities,etc.,frombeingintroducedinto themach…
3-55
3
Periodic maintenance items
5.7 Controller
5.7.1 Cleaning the filter
There are 2 filter types that require cleaning, and they are located at the following 3 positions:
System controller filter : 1 filter at rear center of machine.
Servo controller filters
: 2 filters, 1 at the front right side, and 1 at the right side as viewed when facing the machine's rear.
1
Detach the batch change carriage.
Detach the batch change carriage, and
turn the machine power OFF to ensure
safety.
2
Remove the front cover and duct.
Remove the front cover and duct as
described in Chapter 1, section "2.1
Removing the tape cutter duct".
n
NOTE
The figure at right shows the rear side. There is no need
to remove the front-side cover and duct.
3
Remove the covers.
As shown in the figure at right, remove the
rear center cover and the right-side cover.
53370-N5-00
4
Remove the filter.
Use a Phillips screwdriver to loosen the
screws which secure the filter, then extract
the filter.
53371-N5-00
5
Clean the filter.
Use a vacuum cleaner or vacuum tool to
remove the dust sticking to the filter.
n
NOTE
If a filter replacement is not required, proceed to Step 7.
6
Replace the filter.
If the filter is too soiled to be cleaned by
air-blowing, or if it is in a degraded
condition, replace it with new one as shown
in the figure at right.
7
Reinstall the filter.
Reinstall the filter by reversing its removal
procedure.
8
Reattach the covers.
Removing the cover (machine rear)
Step 2, 3
Remove these 3 coversDuct
Front cover
Removing the filter
System controller
Servo controller
Step 4
Slide the top side
toward the front
Filter
Slide the top side
toward the rear
Filter securing screw
Filter securing screw
Filter
3-56
3
Periodic maintenance items
5.8 Air / mist filter
5.8.1 Cleaning the filter and cup
Airfiltersandoilmistfiltersareinstalledtopreventoil,water,andimpurities,etc.,frombeingintroducedinto
themachinefromtheaircompressor.Theproceduresforinspecting,cleaning,andreplacingthesefiltersare
givenbelow.
c
decoupled.
1
Check the inside of the filer cup.
Check for oil or water deposits in the filter
cup through the window. If the window is
dirty, follow the steps below to clean the
filter cup.
TIP
The drain cock at the bottom of the filter cup is an
auto-drain type. It automatically drains the oil or water
when deposited in the cup. We recommend
connecting a hose to this drain cock.
2
Remove the filter cup.
While pressing the cup's button, rotate the
cup in the direction shown at right, then pull
downward to remove the cup. The removed
cup has a double construction. Only the
transparent inner cup requires cleaning.
53372-N5-00
3
Clean the inside of the filter cup.
1. Lightly clean the filter cup with water.
2. Then, pour water-diluted neutral
detergent into the filter cup and clean
the inside while shaking it.
3. Air blow the filter cup and wipe away
any moisture with clean cloth or paper.
53373-N5-00
4
Check the filter media status.
Rotate the media to remove it, and check it
for soiling and clogging. If soiled, replace it
with a new media indicated in the
Consumable Parts List.
5
Install the media and cup.
Install the media and cup by reversing the
removal procedure given above.
6
Reconnect the air hose to the air
coupler.
After connecting the air hose, check that no
air is leaking.
Removing the cup
Step 2
Filter cup (inner)
Air filter
Oil mist filter
Button
Removing and checking the filter media
Step 4
Mist filter
Air filter
Chapter 4 Long-term inspection and other
maintenance
Contents
1
1
2
2.1 Replacing the blow station filter 4-2
2.2 UPS battery 4-3
3.
4-4
5
3.1.1 AZ axis 4-5
3.1.2 Both sides of cATS 4-5
3.2 6-month inspection 4-6
3.2.1 AH axis 4-6
3.2.2 Magazine shaft 4-6
3.2.3 Pickup station (pallet clamp) 4-7
3.2.4 Pickup station (vertical guide) 4-7
8
4.1 Removing the pumps and making preparations 4-9
0
4.2.1 Removing the head cover and cylinder 4-10
4.2.2 Removing the pressing plate and cup packing 4-12
4.2.3 Removing the cylinder parts 4-12
4.3 Reinstalling the replacement parts 4-13
4.3.1 Reinstalling the cup packing and pressing plate 4-13
4.3.2 Reinstalling the cylinder parts 4-13
4.3.3 Reassembling the head cover 4-14
