YSM40R_2-Beam_KMB_PL
P AR TS LIST KMB-100-1607(PL) High-density Modular Y SM40R ( 2-Beam )
KMB-100-1607
1 / 5
Contents
1 Base Section
2 Cover Section
3 Feeder Holder Section
1-1 Base 1-2 Sub Assy / UPS
2-1 Top Cover (Right side) 2-2 Top Cover (Left side) 2-3
Top Cover (Ceiling) / Conv.(UPS)
2-4 Door / USB-Box
2-5 Base
3-1 Bank FES46 Rail Guide 3-2
Bank FES46 Locate Pin / Fan
3-3 Bank FES46 Base
3-4
Cover FES46 Moving Part
3-5
Cover FES46 Base / Sensor
3-6 Reel Holder
3-7 Carriage FES46 3-8
Clamp FES46 Cylinder / Guide
3-9
Clamp FES46 ARM / Cam Follower
KMB-100-1607
2 / 5
Contents
5 Head Section 4 Moving-axis Section
4-7
Y-axis Frame / Cable (2-Beam)
5-1 Head (MU) 5-2 R-axis Assy (MU) 5-3 Head Shaft Assy (MU)4-1 X-Motor / BS (2-Beam) 4-3
X-Holder Head (2-Beam)
4-2
X-Guide / Manufold (2-Beam)
4-4
X-Duct / I/O Box (2-Beam)
4-5
X-Frame / Y-Connection (2-Beam)
4-6 Y-axis (2-Beam) 5-4
Body Head Sub Assy (MU)
5-9 R-axis Assy 2 (FL)5-8 R-axis Assy 1 (FL)5-7 Z-axis Assy (FL)
5-6 Servo / I/O-BOX (FL)5-5 Head (FL)
