Check Code Display Section A Display Section B
030401 Operation Please input barcode data by manual input screen.
Requirement
030402 Operation Please check the operation in "pass" mode.
Requirement
030403 Operation X/Y chute P.C.B. detection is one side mode.
Requirement
030404 Operation Please exit P.E.C. manual adjustment mode.
Requirement (Click right and left button)
030405 Operation Please wait for a while.
Requirement (Now Machine is initializing.)
030406 Operation Nozzle level mismatch with component thickness (t). Collect
Requirement component and attach one again.
030407 Operation Recognition fail. Check data and component position.
Requirement
030408 Operation The current program changed. Please perform setup operation.
Requirement
030409 Operation Please check final mount step condition for eye adjustment.
Requirement This mount position was detected outside of the possible range.(PEC
position)
030410 Operation This teach point was detected outside of the possible range.
Requirement
030411 Operation This origin point was detected outside of the possible range.
Requirement (PEC position)
030412 Operation This destinate step was detected outside of the possible range.
Requirement (PEC position)
050101 No Current Select the current program.
050102 No Current Incorrect data found within internal current program. Please retry
program change.
050201 Setup Check Set up X/Y chute width.
050202 Setup Check Set up L conveyor width.
050203 Setup Check Set up R conveyor width.
050204 Setup Check Set up conveyor width.
050205 Setup Check Move the X/Y chute up.
050206 Setup Check Set up PCB support pins up/down.
050207 Setup Check Set up PCB locate lever.
050208 Setup Check Please input transfer stroke data.
050209 Setup Check Please input Zero Position.
05020a Setup Check Please input PCB locate lever size.
05020b Setup Check Set up X/Y chute width for Y-clamp action.
05020c Setup Check Please Transfer and Set P.C.B. on the X/Y table. (X/Y table on
P.C.B. is non clamp condition.)
0509-002 2-7 AIM01ETRP
1.2 "CHECK" Windows
Check Code Display Section A Display Section B
05020d Setup Check The P.C.B.-Clamp was detected Vacuum Leak. Please check the
P.C.B. -Clamp condition or Vacuum Leak Setting level.
05020e Setup Check "X-Clamp Pressure set value. ( "0" value is not active)."
050301 Recognition Data Please check recognition nozzle data and carry out data trans again.
Missing
050302 Recognition Data Please check comp recog lighting data and carry out data trans
Missing again.
050303 Recognition Data Please check recog camera mag data and carry out data trans
Missing again.
050304 Recognition Data Please check recog camera offset data and carry out data trans
Missing again.
050305 Recognition Data Please check recog camera gain level data and carry out data trans
Missing again.
050306 Recognition Data Please check recog nozzle gain level data and carry out data trans
Missing again.
050307 Recognition Data Please check comp recog data and carry out data trans again.
Missing
050308 Recognition Data Please check recog execution mode data and carry out data trans
Missing again.
070101 Front Safety Door Close the safety door and zero all device with the [ZERO] button.
070201 Rotary Wheel Pull on the rotary wheel handle.
070301 Front Area Sensor Remove foreign substance.
070401 Unavailable Data Input available feeder No. in current program.
070402 Unavailable Data Input available placement step in current program.
090101 Disengaged PCB Set P.C.B. on the X/Y table.
090201 Chute Lower Limit Move the X/Y chute down.
090301 Feeder Carriage Separate both feeder carriages and zero all devices with the [ZERO]
Collision button.
0509-002 2-8 AIM01ETRP
1.2 "CHECK" Windows
Check Code Display Section A Display Section B
090401 Cam Phase Check the cam positioner.
090402 Cam Phase Re-adjust or repair the cam shaft if necessary.
090501 Out Of Limit Zero all device with the [ZERO] button.
090502 Out Of Limit Feeder carriage #1 limit error has been detected.Moving the feeder
carriage #1.Check the feeder carriage #1 limit sensor .
090503 Out Of Limit Feeder carriage #2 limit error has been detected.Moving the feeder
carriage #2.Check the feeder carriage #2 limit sensor .
090504 Out Of Limit Feeder carriage #3 limit error has been detected.Moving the feeder
carriage #3.Check the feeder carriage #3 limit sensor .
090505 Out Of Limit Feeder carriage #4 limit error has been detected.Moving the feeder
carriage #4.Check the feeder carriage #4 limit sensor .
090601 Linear Measure Alarm Press the [POWER OFF] button once and press the [POWER
ON] button.
090701 Out Of Feeder Axis Zero all device in manual mode or with the [ZERO] button.
Stationary Position
090702 Out Of Feeder Axis Check the feeder.
Stationary Position
090703 Out Of Feeder Axis Check feeder motor 1 & 2.
Stationary Position
090704 Out Of Feeder Axis Please check area around feeder carriage located at its home
Stationary Position position #1.
090705 Out Of Feeder Axis Please check area around feeder carriage located at its home
Stationary Position position #2.
090801 Rotary Turret Origin Adjust rotary turret angle to 0° or 360°.
090901 Furnace Signal Check the furnace signal.
090a01 Oil Cooler Alarm Check the cooling oil.
090b01 Cooling FAN Alarm Check the cooling FAN.
091001 Recognition Ready Wait until recognition unit is ready to work.
0b0101 Feeder Carriage Not Press the [F1 READY] button to set feeder carriage #1 in ready
Ready Switch mode.
0b0102 Feeder Carriage Not Press the [F2A READY] button to set feeder carriage #2 in ready
Ready Switch mode.
0b0103 Feeder Carriage Not Press the [F3B READY] button to set feeder carriage #3 in ready
Ready Switch mode.
0b0104 Feeder Carriage Not Press the [F2B READY] button to set feeder carriage #2 in ready
Ready Switch mode.
0b0105 Feeder Carriage Not Press the [F3A READY] button to set feeder carriage #3 in ready
Ready Switch mode.
0b0106 Feeder Carriage Not Press the [F4 READY] button to set feeder carriage #4 in ready
Ready Switch mode.
0b0107 Feeder Carriage Not Still have feeder carriage interlock. Restore Load Power again.
Ready Switch
0509-002 2-9 AIM01ETRP
1.2 "CHECK" Windows
