Check Code Display Section A Display Section B
800701 Alternated Block Comp. Missing(sensor)
800702 Alternated Block Comp. Vertical(sensor)
800703 Alternated Block Comp. Missing(recog.)
800704 Alternated Block Comp. Recog. Error
800705 Alternated Block Shortage of component
800706 Alternated Block Start recovery mode.
800707 Alternated Block Comp. Thickness(sensor)
800708 Alternated Block Comp. Pickup Diff.(recog.)
800709 Alternated Block Comp. Reverse(recog.)
(Contents) The block alternate function has worked.
(Description) Check the related feeder and take necessary measures such as
component replenishment.
800801 Start Auto Recovery Comp. Missing(sensor)
Mode
800802 Start Auto Recovery Comp. Vertical(sensor)
Mode
800803 Start Auto Recovery Comp. Missing(recog.)
Mode
800804 Start Auto Recovery Comp. Recog. Error
Mode
800805 Start Auto Recovery Shortage of component
Mode
800806 Start Auto Recovery Comp. Thickness(sensor)
Mode
800807 Start Auto Recovery Comp. Thickness(sensor)
Mode
800808 Start Auto Recovery Comp. Pickup Diff.(recog.)
Mode
800809 Start Auto Recovery Comp. Reverse(recog.)
Mode
(Contents) The automatic (delayed) recovery function has worked.
(Description) Check the related feeder and take necessary measures such as
component replenishment.
0509-002 2-16 AIM01ETRP
1.3 Machine lnformation
Check Code Display Section A Display Section B
800901 OAlarm For The tape end was detected.
Shortage of Comp.
800902 OAlarm For Few components to feed.
Shortage of Comp.
(Contents) Self-Diagnostics Error Message
(Description) The automatic operation will stop soon due to component shortage.
Prepare for component replenishment.
800A01 Product Information Finished product interval :
800A02 Product Information Auto run interval :
800A03 Product Information Nozzle usage interval :
800A04 Product Information Product started by RUN MODE "PASS"Operation.
800B01 Machine Interface No signal from furnace.
Signal
800C01 Cancel Recovery on
(Contents) Self-Diagnostics Error Message
(Description) Confirm the displayed contents.
800D01 Maintenance Trash box fill up warning. (notice count over)
Warning
800D02 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning Weekly)
800D03 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning 1-Monthly)
800D04 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning 3-Monthly)
800D05 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning 6-Monthlyy)
800D06 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning Designate #1)
800D07 Maintenance Keep the machine condition.(maintenance cycle time : Oil-Checkup/
Warning Designate #2)
(Contents) Self-Diagnostics Error Message
(Description) Follow the displayed instructions for maintenance work.
0305-001 2-17 AIM01ETRP
1.3 Machine lnformation
Check Code Display Section A Display Section B
800D08 Maintenance Keep the machine condition.(maintenance cycle time : Upkeep-
Warning Checkup/Nozzle)
800D09 Maintenance Keep the machine condition.(maintenance cycle time : Upkeep-
Warning Checkup/Filter #1)
800D0A Maintenance Keep the machine condition.(maintenance cycle time : Upkeep-
Warning Checkup/Filter #2)
800D0B Maintenance Keep the machine condition.(maintenance cycle time : Designate-
Warning Checkup/Item #1)
800A0C Maintenance Keep the machine condition.(maintenance cycle time : Designate-
Warning Checkup/Item #2)
800D0D Maintenance Keep the machine condition.(maintenance cycle time : Designate-
Warning Checkup/Item #3)
800D0E Maintenance Component box fill up warning.(notice count over)
Warning
(Contents) Self-Diagnostics Error Message
(Description) Follow the displayed instructions for maintenance work.
800E01 Program Change Check the setup of machine.(program change completed)
Warning
800E02 Program Change "Check the setup of machine.(Program change completed. Run
Warning Mode changed to "PASS".)"
800F01 SIF Information The fdr.was not recorded SIF data exists. Please record by
mnl.operation.
800F02 SIF Information The SIF data was changed. Please record by mnl.operation.
800F03 SIF Information The fdr. was not recorded SIF data exists.
Please record by mnl.operation.
800F04 SIF Information The fdr.was not recorded SIF data exists.
800F05 SIF Information "Performing this operation may cause unrecorded SIF data lost.
Press Enable SW during lit, if continue."
800F06 SIF Information Changing the feeder alternate condition to 'Disable' for SIF found
empty feeder.
800F07 SIF Information Changing the feeder alternate condition to 'Disable' for SIF found
missing feeder.
(Contents) Self-Diagnostics Error Message
(Description) Confirm the displayed contents.
0509-002 2-18 AIM01ETRP
