Error ID Item Description
030502 Comp. Pick-Up (Z) Axis User constant breakdown.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030503 Comp. Pick-Up (Z) Axis Main circuit encoder error
Servo Alarm
030504 Comp. Pick-Up (Z) Axis User constant setting error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030505 Comp. Pick-Up (Z) Axis Combination error
Servo Alarm
030509 Comp. Pick-Up (Z) Axis Dividing ratio setting error
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
03050a Comp. Pick-Up (Z) Axis Encoder model unmatched
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030510 Comp. Pick-Up (Z) Axis Overcurrent or Heat Sink Overheated.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030530 Comp. Pick-Up (Z) Axis Regeneration error detected
Servo Alarm
030532 Comp. Pick-Up (Z) Axis Regenerative overload
Servo Alarm
030533 Comp. Pick-Up (Z) Axis Main circuit power supply wiring error
Servo Alarm
030540 Comp. Pick-Up (Z) Axis Overvoltage
Servo Alarm
030541 Comp. Pick-Up (Z) Axis Undervoltage
Servo Alarm
030551 Comp. Pick-Up (Z) Axis Overspeed
Servo Alarm
030571 Comp. Pick-Up (Z) Axis Overload: high load
Servo Alarm
030572 Comp. Pick-Up (Z) Axis Overload: low load
Servo Alarm
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0509-002 2-42 AIM01ETRP
Error ID Item Description
030573 Comp. Pick-Up (Z) Axis Dynamic break overload
Servo Alarm
030574 Comp. Pick-Up (Z) Axis Overload of Surge Current Limit Resistor
Servo Alarm
03057a Comp. Pick-Up (Z) Axis Heat sink overheated
Servo Alarm
030581 Comp. Pick-Up (Z) Axis Encoder backup error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030582 Comp. Pick-Up (Z) Axis Encoder checksum error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
030583 Comp. Pick-Up (Z) Axis Absolute encoder battery alarm
Servo Alarm
030584 Comp. Pick-Up (Z) Axis Encoder data error.
Servo Alarm [Shutdown touch sw key and mainbreakersw off.]
030585 Comp. Pick-Up (Z) Axis Encoder overspeed
Servo Alarm
030586 Comp. Pick-Up (Z) Axis Encoder overheated
Servo Alarm
0305b1 Comp. Pick-Up (Z) Axis Reference speed input read error
Servo Alarm
0305b2 Comp. Pick-Up (Z) Axis Reference torque input read error
Servo Alarm
0305b3 Comp. Pick-Up (Z) Axis Current detection error
Servo Alarm
0305b6 Comp. Pick-Up (Z) Axis Gatearay error
Servo Alarm
0305bf Comp. Pick-Up (Z) Axis System alarm.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305c1 Comp. Pick-Up (Z) Axis Servo overrun detected
Servo Alarm
0305c6 Comp. Pick-Up (Z) Axis Closed loop a/b
Servo Alarm
0305c7 Comp. Pick-Up (Z) Axis Closed loop c
Servo Alarm
0305c8 Comp. Pick-Up (Z) Axis Encoder clear error (multi turn limit).
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305c9 Comp. Pick-Up (Z) Axis Encoder communications error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305ca Comp. Pick-Up (Z) Axis Encoder parameter error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305cb Comp. Pick-Up (Z) Axis Encoder echoback error.
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0509-002 2-43 AIM01ETRP
Error ID Item Description
0305cc Comp. Pick-Up (Z) Axis Multiturn limit disagreement
Servo Alarm
0305d0 Comp. Pick-Up (Z) Axis Position error pulse overflow
Servo Alarm
0305d1 Comp. Pick-Up (Z) Axis Motor-load position error over
Servo Alarm
0305e0 Comp. Pick-Up (Z) Axis No option
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305e1 Comp. Pick-Up (Z) Axis Option time out
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305e2 Comp. Pick-Up (Z) Axis Option WDC error
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305e5 Comp. Pick-Up (Z) Axis WDT error
Servo Alarm
0305e6 Comp. Pick-Up (Z) Axis Communication error
Servo Alarm
0305e7 Comp. Pick-Up (Z) Axis Application module detection error
Servo Alarm
0305ea Comp. Pick-Up (Z) Axis Servo pack error
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305eb Comp. Pick-Up (Z) Axis Servo pack access error
Servo Alarm [Shutdown touch sw key and mainbreaker sw off.]
0305ec Comp. Pick-Up (Z) Axis Servo pack WDC error
Servo Alarm
0305ed Comp. Pick-Up (Z) Axis Command not execute
Servo Alarm
0305f1 Comp. Pick-Up (Z) Axis Power line open phase
Servo Alarm
0305f5 Comp. Pick-Up (Z) Axis Servomotor disconnection alarm
Servo Alarm
0305f6 Comp. Pick-Up (Z) Axis Servomotor disconnection alarm
Servo Alarm
030590 Comp. Pick-Up (Z) Axis Excessive position error warning
Servo Alarm
030591 Comp. Pick-Up (Z) Axis Overload warning
Servo Alarm
030592 Comp. Pick-Up (Z) Axis Regenerative overload warning
Servo Alarm
030594 Comp. Pick-Up (Z) Axis Data setting warning
Servo Alarm
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-002 2-44 AIM01ETRP
3.3 Error IDs and Remedial Procedures
