Error ID Item Description
0f0606 Transfer P.C.B. Detection The P.C.B. has not passed from the input conveyor into table
chute. (P.C.B. was taken on input conveyor.)
0f0607 Transfer P.C.B. Detection The P.C.B. has not passed from the table chute into the out-
put conveyor. (The P.C.B. disappeared.)
0f0608 Transfer P.C.B. Detection The P.C.B. has not passed from the table chute into the out-
put conveyor. (P.C.B. was taken on output conveyor.)
0f0609 Transfer P.C.B. Detection The P.C.B. has not passed from the table chute into the out-
put conveyor. (P.C.B. on x/y table chute was not able to move
to its outlet.)
0f060a Transfer P.C.B. Detection The P.C.B. appeared when the table chute descended.
0f060b Transfer P.C.B. Detection The P.C.B. was out of detection when the table chute de-
scended. Check P.C.B. on x/y table.
0f060c Transfer P.C.B. Detection The P.C.B. appeared when the table chute ascended.
0f060d Transfer P.C.B. Detection The P.C.B. was out of detection when the table chute as-
cended. Check P.C.B. on x/y table.
0f060e Transfer P.C.B. Detection The P.C.B. was detection by inside positon sensor when the
table chute was not descended. Check P.C.B. on x/y table.
0f060f Transfer P.C.B. Detection The P.C.B. has not passed from the table chute into the out
put conveyor. (Two P.C.B. was exist on xy chute.)
0f0610 Transfer P.C.B. Detection The P.C.B. has not passed from the table chute into the out
put conveyor. (Two P.C.B. was exist on xy chute.)
(Cause 1) An error was detected during P.C.B. transfer.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause of
the error.
0f0701 Transfer Overtime Transfer has not descended smoothly resulting in an
overtime alarm. ; BPH40
0f0702 Transfer Overtime Transfer has not ascended smoothly resulting in an overtime
alarm. ; BPS1
(Cause 1) This error occurs when the transfer does not descend or ascend while a P.C.B. is
being transferred during automatic operation.
The sensor may be dirty.
(Cause 2) This error occurs because the cylinder cannot take the specified action (expansion
and contraction) and the sensor is not turned ON while the P.C.B. transfer is as-
cending.
The sensor may be dirty.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause
due to which the transfer does not descend or ascend.
When this error still occurs although the transfer descends or ascends, the sen-
sor may be dirty. In this case, clean the sensor and zero the transfer.
(Remedy 2) Wipe off dirt on the sensor and zero the transfer.
0509-002 2-94 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
0f0703 Transfer Overtime Table chute has not descended smoothly resulting in an
overtime alm. ; ls15/BPH61
0f0704 Transfer Overtime Table chute has not ascended smoothly resulting in an
overtime alm. ; BPH60
(Cause 1) This error occurs when the X/Y chute does not descend or ascend.
• The sensor may be dirty.
• The P.C.B. was trapped in the X/Y chute.
• The reference hole of the P.C.B. is not suitable for the outline reference pin.
• The reference hole of the P.C.B. is small and the P.C.B. does not come off.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause of
the error. Then, perform the zeroing operation
0f0705 Transfer Overtime The transfer was not completely sent during the set time.
0f0706 Transfer Overtime The transfer was not completely returned during the set time.
(Cause 1) This error occurs when the machine does not take a P.C.B. forward or backward
transfer action.
The sensor may be dirty.
(Cause 2) The P.C.B. transfer belt may be slack.
(Remedy 1) Press the [RETURN] button to cancel the error display and remove the cause
due to which the machine does not take a P.C.B. forward or backward transfer
action.
Wipe off dirt on the sensor and perform the zeroing operation.
(Remedy 2) It is required to replace the P.C.B. transfer belt because it is worn out.
Contact our service personnel for details.
0f0707 Transfer Overtime The transfer was not completely sent.
0f0708 Transfer Overtime Upper limit of transfer was detected when transfer has not
descended smoothly.
0f0709 Transfer Overtime Lower limit of transfer was detected when transfer has not
ascended smoothly.
0f070a Transfer Overtime Upper limit of x/y table chute was detected when table chute
has not descended smoothly.
0f070b Transfer Overtime Lower limit of x/y table chute was detected when table chute
has not ascended smoothly.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-002 2-95 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
0f0801 Transfer Interlock Transfer unable to work because X/Y table was not at origin.
0f0802 Transfer Interlock Transfer unable to work because X/Y table was not running.
0f0803 Transfer Interlock Transfer unable to work because input conveyor was not
run- ning forward.
0f0804 Transfer Interlock Transfer unable to work because input conveyor was not run-
ning backward.
0f0805 Transfer Interlock Transfer unable to work because output conveyor was not
running.
0f0806 Transfer Interlock X/Y table chute was not detected (lower position) while mov-
ing table.; BPH61/BPH70
0f0807 Transfer Interlock Upper limit of x/y table chute was detected. (lower position);
BPH60 e/nr
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0f0901 Transfer Data DDMC data communication timeout
Communication Error
0f0902 Transfer Data DDMC board communication error
Communication Error
0f0903 Transfer Data Data checksum error
Communication Error
0f0904 Transfer Data No answer
Communication Error
0f0905 Transfer Data Busy
Communication Error
0f0906 Transfer Data No command
Communication Error
0f0907 Transfer Data No answer from PMD
Communication Error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-001 2-95-1 AIM01ETRP
3.3 Error IDs and Remedial Procedures
