Error ID Item Description
400305 Load Power Circuit The fdr.crg. axis safety guard (a) is open.
400306 Load Power Circuit The fdr.crg. axis safety guard (b) is open.
(Cause 1) The feeder work area safety door was opened.
(Remedy 1) Close the feeder work area safety door after pressing the [RETURN] button and
zero all axes. Then, re-start the operation.
400307 Load Power Circuit Load power-on timeout.
Press [emergency stop] switch.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
400401 Load Control Power Circuit Load power-on timeout.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
400501 Lightning Surge Warning Lightning Surge Protector works; Q204. Load power on with
reset operation.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-002 2-105 AIM01ETRP
3.3 Error IDs and Remedial Procedures
(41 Data)
Error ID Item Description
410101 PLACEMENT NOZZLE APPROPRIATE NOZZLE MISSING.
"Check the Nozzle layout data or Nozzle skip conditon."
(Cause 1) A nozzle different from the nozzle-related data is attached.
(Remedy 1) Check the attached nozzle and the "Nozzle Data" window (described in "4. Nozzle
Data" in "Section 5 (Vol. 3: Programming and Machine Data)" and reset the ma-
chine to its normal condition.
410201 Alternate Mode Available fdr.carriage is not found.
(Cause 1) A wrong parameter is set in the "Alternate" tab sheet.
(Remedy 1) Check the carriage to be used and correct the wrong parameter if any.
410301 Current Pattern Program
No Exist
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform a program change operation.
When the program change operation cannot be performed, contact our service
personnel.
410401 Component Cannot refer to component data.
(Cause 1) A mistake is found in the placement feeder location data of the pattern program
data.
(Remedy 1) Check the placement feeder location data. If necessary, correct the mistake.
410501 Placement Data Already placed
410502 Placement Data Placement step missing. Start and recovery with WARM
START.
410503 Placement Data Placement Complete step missing. Start and recovery with
Manual or Warm START.(Cycle stop mode)
410504 Placement Data Placement complete step missing. Check the P.C.B.
now.(Running cancel mode.)
410505 Placement Data Placement complete step missing. Check the P.C.B. (Run
ning countinue mode.)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Follow the described instructions and reset the machine to its normal condition.
0509-002 2-106 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
410601 Component Data Available nozzle is not found.
"Check the Nozzle layout data or Nozzle skip conditon."
410701 Nozzle Type
(Cause 1)A correct nozzle may not be attached or the attached nozzle may not conform to the
placement head/nozzle data and the nozzle type data.
(Remedy 1) Check the nozzle attached to the head of the machine.
Refer to the "4. Nozzle Data" in "Section 5 (Vol. 3: Programming and Machine
Data)" and check the placement head/nozzle data and the nozzle type data.
410801 Current Pattern Program
No Exist
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform a program change operation.
When the program change operation cannot be performed, contact our service
personnel.
410901 PEC Inspect Data Overflow P.E.C. inspect data count.
410a01 Pattern Program Data 'E' is input to the control command of P data.
It is not possible to use it at the R&C bad mark function.
(Cause 1) The pattern program data is wrong.
(Remedy 1) Create a correct pattern program.
0509-001 2-106-1 AIM01ETRP
