(43 Self-Diagnostics 1) Error ID Item Description 430101 Nozzle Change Nozzle change action error . (DD-head camfree position) (Cause 1) Self-Diagnostics Error Message (Remedy 1) Zero all axes and re-start the operation.…
Error ID Item Description
420301 Output Cnvr. Overtime P.C.B. to output machine was not transferred.
420302 Output Cnvr. Overtime P.C.B. on output cnvr. was not able to move to its outlet.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
420401 Input Buffer Cnvr. Inp. machine send sig. turned off before P.C.B. reached in-
P.C.B. Detection put cnvr.
420402 Input Buffer Cnvr. P.C.B.
,
s were at inlet and outlet of input buffer cnvr.
P.C.B. Detection
(Cause 1) The P.C.B. transfer signal from the input machine was turned off before the P.C.B.
was detected by the P.C.B. detection photosensor at the input conveyor outlet side.
There are two P.C.B.’s on the input conveyor.
(Remedy 1) Adjust the position of the P.C.B. detection photosensor (outlet).
The P.C.B. detection photosensor (outlet) is defective and required to be replaced
with a new one.
420501 Input Cnvr. P.C.B. Detection The sensor position is illegal setting.
420502 Input Cnvr. P.C.B. Detection P.C.B.
,
s were at inlet and outlet of input cnvr.
420503 Input Cnvr. P.C.B. Detection P.C.B. on inp. cnvr. was not able to move to its transfer
action.
(Cause 1) The P.C.B. was carried back to the P.C.B. transfer claw during automatic opera-
tion. Or, the P.C.B. is shifted out of the coverage of the P.C.B. detection photosensor.
• The P.C.B. detection photosensor is attached to a wrong position.
• The X value of "P.C.B. SIZE" has exceeded the range of setting.
(Remedy 1) Press the [RETURN] button to cancel the error display and zero the P.C.B. trans-
fer.
Adjust the position of the P.C.B. detection photosensor.
Set the correct X value for "P.C.B. SIZE".
420601 Output Cnvr. P.C.B. Detection Out. machine work req. sig. turned off before P.C.B. trns.act
completed.
420602 Output Cnvr. P.C.B. Detection P.C.B. on output cnvr. was not able to move to its outlet.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0403-002 2-108 AIM01ETRP
3.3 Error IDs and Remedial Procedures
(43 Self-Diagnostics 1)
Error ID Item Description
430101 Nozzle Change Nozzle change action error. (DD-head camfree position)
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
430207 NOZZLE POSITION Nozzle posture system alarm signal was detected.
430208 NOZZLE POSITION Communication error in nozzle posture system.
(Cause 1) The optical beam was not set in the "E/R" or the "E/NR" condition due to dirt on the
sensor. (E/R: Light Emitted and Received, E/NR: Light Emitted and Not Received)
The sensor may be defective.
(Remedy 1) Press the [RETURN] button to cancel the error display and check that no dirt
adheres to the sensor.
430209 NOZZLE POSITION The selected nozzle was erroneously positioned. ;Nozzle
posture detection
(Cause 1) The selected nozzle moved down, passing over the low level at Station #10.
Self-Diagnostics Error Message.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
43020a NOZZLE POSITION The selected nozzle level was not at high position. ;Nozzle
posture detection
43020b NOZZLE POSITION The selected nozzle level was not at low position. ;Nozzle
posture detection
(Cause 1) When the nozzle change operation was completed at Station #10, the nozzle detec-
tion sensor could not detect the normal level (High/Low Level) of the nozzle.
(Defective Nozzle Sliding Movement)
(Remedy 1) Check the contents of the error and re-start the operation.
When the error still occurs frequently after the operation is re-started, adjust the
object head and check the sliding movement.
Refer to "1.4.5 Disassembly, Cleaning, and Lubrication of Miniature Stroke Bear-
ing" in "Section 1" for the adjustment.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-003 2-109 AIM01ETRP
3.3 Error IDs and Remedial Procedures
0509-004 2-110 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
43020c NOZZLE POSITION The unselected nozzle was erroneously positioned. ;Nozzle
posture detection
(Cause 1) The optical beam was not set in the "E/R" or the "E/NR" condition due to dirt on the
sensor. (E/R: Light Emitted and Received, E/NR: Light Emitted and Not Received).
The sensor may be defective.
(Cause 2) This error occurs when the nozzle almost comes off at Station #8 and touches the
component discharge plate.
(This error occurs during automatic or manual operation.)
(Remedy 1) Confirm that no dirt adheres to the sensor. Or, it may be necessary to replace
the sensor with a new one because it may be defective.
Before replacing the sensor, contact our service personnel for some advice.
(Remedy 2) Check the head at Station #8. Subsequently, perform the reverse rotation opera-
tion to move the head back toward the front side of the machine. Then, insert the
nozzle deep inside.
43020d NOZZLE POSITION The selected nozzle level was not at high position. ;Nozzle
posture detection
43020e NOZZLE POSITION The selected nozzle level was not at low position. ;Nozzle
posture detection
(Cause 1) The component which should be placed on the P.C.B. was carried back.
(Remedy 1) Check the contents of the error and re-start the operation.
Refer to "2.7 Component Backtrack Detection Function" (Section 2) in "Vol. 2"
for details.
43020f NOZZLE POSITION The selected nozzle was not at position. ;Nozzle posture
detection
(Cause 1) Self-Diagnostics Error Message
The nozzle detection sensor could not detect the nozzle stationary position (the
nozzle level at the stationary position) at Station #10 for the nozzle which was about
to pick up a component.
(Defective Nozzle Sliding Movement)
(Cause 2) The end of the nozzle is broken (lost).
(Remedy 1) Check the contents of the error and re-start the operation.
When the error still occurs after the operation is re-started, adjust the object
head and check the sliding movement.
Refer to "1.4.5 Disassembly, Cleaning, and Lubrication of Miniature Stroke Bear-
ing" in "Section 1" for the adjustment.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Replace the object nozzle with another one.
