Error ID ltem Description
440801 Cutter THE CUTTER FORWARD CONFIRMATION WAS NOT ACTI-
VATED. ; BPH32
440802 Cutter THE CUTTER RETURN CONFIRMATION WAS NOT ACTI-
VATED. ; BPH33
(Cause 1) An optical beam of the sensor was not shielded at all.
This error occurs when the cutter blades do not close completely.
Example: The cutter blades were damaged because they were activated to cut com-
ponents.
(Remedy 1) Press the [RETURN] button to cancel the error display and check the cutter
blades.
• If necessary, replace the cutter blades with new ones.
• Check the ON/OFF operation of the cutter forward movement check photosensor
(BPH32) and the cutter backward movement check photosensor (BPH33) in
the cutter section through the manual subsystem operation in the "MNL OPN."
window.
0509-001 2-119-1 AIM01ETRP
3.3 Error IDs and Remedial Procedures
(45 Recognition Communication)
Error ID ltem Description
450101 PEC INSPECT
450102 PEC INSPECT Time-Out Error
450103 PEC INSPECT GUI starting failure.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-002 2-120 AIM01ETRP
3.3 Error IDs and Remedial Procedures
(46 P.E.C. Recognition)
Error ID ltem Description
460101 PEC Inspect P.E.C. Mark #1 (Global)
460201 PEC Inspect P.E.C. Mark #2 (Global)
460301 PEC Inspect P.E.C. Mark #3 (Global)
460401 PEC Inspect P.E.C. Mark #1 (Image)
460501 PEC Inspect P.E.C. Mark #2 (Image)
460601 PEC Inspect P.E.C. Mark #3 (Image)
460701 PEC Inspect P.E.C. Mark #1 (Local)
460801 PEC Inspect P.E.C. Mark #2 (Local)
460901 PEC Inspect P.E.C. Mark #3 (Local)
460a01 PEC Inspect P.E.C. Recognition Test
460b01 PEC Inspect P.E.C. Recog. Light Teach
460c01 PEC Inspect Error Response of P.E.C. Recog. Command
Refer to "4.3.3 P.E.C. Recognition Errors" for "(Cause 1)” and "(Remedy 1)".
460e01 PEC Inspect (Re_trial) P.C.B. position gap was detected at P.E.C. re-trial check
(Cause 1) Self-Diagnostics Error Message
The result of the P.E.C. re-trial check operation was out of the specified permitted
value.
(Remedy 1) Check the results of the detection in the exclusive window. After that, check how
the P.C.B. is positioned on the X/Y table.
0509-003 2-121 AIM01ETRP
3.3 Error IDs and Remedial Procedures
