(49 Control P.C.B.)
Error ID ltem Description
490101 CPU1 Board Error in an internal communication interruption program.
Please turn off a breaker.
490102 CPU1 Board Error in an internal data reception program. Please turn off a
breaker.
490103 CPU1 Board Error in an internal data transmitting program. Please turn off
a breaker.
490201 CPU2 Board
490202 CPU2 Board Memory allocation error.
490203 CPU2 Board System error occurred.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490301 Recognition Board Recognition board was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
490401 HLSC2 Board HLSC2 board was not detected.
490402 HLSC2 Board H1 board was not detected.
490403 HLSC2 Board System error occurred.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-003 2-123 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
490501 EB005 Board EB005 board was not detected.
490502 EB005 Board Flash write error
490503 EB005 Board RAM read/write error
490504 EB005 Board Init Flash write error
490505 EB005 Board Flash read/write error
490506 EB005 Board Binary data error
490507 EB005 Board Wdt error
490601 Serial I/O Board Serial I/O Board was not detected.
490602 Serial I/O Board Serial I/O Board(option) was not detected.
490701 HLS Satellite HLS Satellite H1 was not detected.
490702 HLS Satellite HLS Satellite H2 was not detected.
490703 HLS Satellite HLS Satellite H3 was not detected.
490704 HLS Satellite HLS Satellite ETC1 was not detected.
490705 HLS Satellite HLS Satellite ETC2 was not detected.
490706 HLS Satellite HLS Satellite F12 was not detected.
490707 HLS Satellite HLS Satellite F34 was not detected.
490708 HLS Satellite HLS Satellite T1 was not detected.
490709 HLS Satellite HLS Satellite XY was not detected.
49070a HLS Satellite HLS Satellite FR was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-003 2-124 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
490801 Serial I/O Controller Linear measure controller was not detected.
490802 Serial I/O Controller Oil cooler controller was not detected.
490803 Serial I/O Controller CAM positioner controller was not detected.
490804 Serial I/O Controller BFC DCU controller (option) was not detected.
490805 Serial I/O Controller SIF DCU controller (option) was not detected.
490806 Serial I/O Controller BCR controller (option) was not detected.
490807 Serial I/O Controller BCR controller (option) was not detected.
490808 Serial I/O Controller BBR BCR controller (option) was not detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0403-002 2-125 AIM01ETRP
3.3 Error IDs and Remedial Procedures
