(67 Teaching Dust/Dirt Detection Diffusion Plate/Nozzle)
Error ID ltem Description
670101 Nozzle Recog. Recognition Error Code
Note: Refer to "4.3.4 Nozzle Recognition Errors" for the detailed error display.
670201 Nozzle Bypass Nozzle Down Error (L)
670202 Nozzle Bypass Nozzle Down Error (H)
670203 Nozzle Bypass Recognition Teach Error
(Cause 1) When the selected nozzle reached the L or H level during operation, the optical
beam of the sensor was shielded (not received).
The sensor may be defective.
(Remedy 1) Remove the dirt on the nozzle end and insert the nozzle deep inside.
The sensor may be defective. If necessary, replace the sensor with a new one.
Before replacing the sensor, contact our service personnel for some advice.
670204 Nozzle Bypass Teach Error Data
(Cause 1) Dirt and dust adhere to the nozzle and an error is found in the nozzle teaching
operation.
(Remedy 1) Remove dirt and dust from the nozzle end and re-perform the nozzle teaching
operation.
670205 Nozzle Bypass Lighting Check
(Cause 1) The diffusion plate of the nozzle may be dusty and dirty or scratched.
(Remedy 1) Clean the diffusion plate or replace it with a new one.
0509-003 2-164 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
670206 Nozzle Bypass Nozzle Level
(Cause 1) This error occurs when the L value exceeds the tolerance in comparison with the
master nozzle in the offset data.
(Remedy 1) Check if a big value is set as an L level of the master level in the offset data.
Check if the nozzle is broken or dirt adheres to the end.
670207 Nozzle Bypass Nozzle Drop
(Cause 1) The nozzle being used has dropped.
(Remedy 1) Check the pertinent nozzle.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
670208 Nozzle Bypass Dummy Nozzle
670209 Nozzle Bypass Manual Bypass
(Cause 1) This appears when some nozzles are bypassed manually.
(Remedy 1) When the [Reset Noz. Bypass] button is pressed in the "Head/Noz. Bypass" tab
sheet of the "OPN. MODE" window (submenu), the manual bypass designation
of all nozzles is all canceled.
67020a Nozzle Bypass Nozzle Change Error. (Cam lock action)
67020b Nozzle Bypass Nozzle Change Error. (Cam Free action)
67020c Nozzle Bypass Cam Origin Error.
67020d Nozzle Bypass Nozzle Teach Error.
67020e Nozzle Bypass Nozzle Posture Detection
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0509-003 2-165 AIM01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
670301 Head Skip Communication Error
670302 Head Skip Head Origin
670303 Head Skip Overtime Head Origin Return
670304 Head Skip Unselected Nozzle Drop
670305 Head Skip Dummy Nozzle
670306 Head Skip Manual Bypass
670307 Head Skip Alarm Error
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
670401 Nozzle Level Nozzle Level (Low) Was More Than Tolerance.
670402 Nozzle Level Nozzle Level (Low) Was Less Than Tolerance.
670403 Nozzle Level Nozzle Level (High) Was More Than Tolerance.
670404 Nozzle Level Nozzle Level (High) Was Less Than Tolerance.
(Cause 1) This error occurs when there is a big difference in nozzle levels in comparison with
the master nozzle during teaching operation.
(Remedy 1) Re-teach the data of the master nozzle.
670501 Master Head Offset Linear Measure System Was At High Position.
670502 Master Head Offset Linear Measure System Was At Low Position.
(Cause 1) The master nozzle or the linear measure detection sensor may not be attached
correctly.
(Remedy 1) Attach the master nozzle correctly.
It is required to adjust the linear measure detection sensor after it is attached
correctly.
0305-001 2-166 AIM01ETRP
