4 . 2 Recognition Error IDs and Controlled Areas Basic System of Recognition Error IDs A recognition error ID is expressed by 10 digits (decimal number) as follows. AA BB C DDDDD Detailed Classification: Detail Code base…

4. Troubleshooting after Error Window (Recognition Error ID)

4.1 Typical Description

Table 4B11

Recognition Error ID Recognition Error Contents, Cause, and Remedy

02**1001** Component was not found.

(Cause 1) The feeder carriage is loaded with a feeder that contains components dif-

ferent from the specified ones.

(Cause 2) The vacuum suction force is too weak.

(Cause 3) An improper nozzle is selected for the components or vice versa.

Mismatching parameters are set in the nozzle type data and the compo-

nent library data.

(Remedy 1) Check if proper components are used.

(Remedy 2) Check the vacuum pressure.

(Remedy 3) Check the parameters in the nozzle type data and the component library

data.

02 **2100** Error in Outward Length Inspection

(Cause 1)

(Remedy 1)

(Continue to next page. )

*1 The recognition error IDs (IDs displayed in the "ERROR" window) are de-

scribed in the numerical order.

"*" will be filled with a numeric character.

*2 Described are the recognition error contents in the "ERROR" window.

*3 Described are the causes and remedial procedures of "*2 Recognition

Error Contents".

The causes and remedies are correlated as follows.

(Cause 1) Æ (Remedy 1)

(Cause 2) Æ (Remedy 2)

(Cause 3) Æ (Remedy 3)

*4 This indicates that the related contents are described subsequently on the

next page.

4. Troubleshooting after Error Window (Recognition Error ID)

0509-004 2-180 AIM01ETRP

*2 *3

4.2 Recognition Error IDs and Controlled Areas

Basic System of Recognition Error IDs

A recognition error ID is expressed by 10 digits (decimal number) as

follows.

AA BB C DDDDD

Detailed Classification: Detail Code based on

Classification of Rec-

ognition Functions

Error Classification: Secondary Classifica-

tion Code of Detailed

Classification

Error Classification: Primary Classifica-

tion Code of Detailed

Classification

Classification of Recognition Functions

Table 4B12

Recognition Error IDs Classification of Recognition Functions

01 Recognition Communication and Data

Check

02 Component Recognition Function

03 P.E.C. Recognition Function

04 Nozzle Recognition Function

10 Various Teaching Functions

13 Broken Circuit of Lamp for Component Rec-

ognition

14 Lighting Control Board-to-Board Communi-

cation

4.2 Recognition Error IDs and Controlled Areas

0305-001 2-181 AIM01ETRP

4.3 Recognition Error IDs and Remedial Procedures

4.3.1 Recognition Communication and Data Errors

AA BB C DDDDD

Detail Code

Secondary Error Classification

1: Recognition Communication

Data Range Error

2: Input Data Assembly Error

3: Input Data Error

Primary Error Classification

10 to 70: Recognition Communication Data Error

90: Recognition Communication Procedure Error

91: Recognition Communication Error

(Command Error)

92: Recognition Communication Error (Response Error)

Classification (01) of Recognition Functions

When an error ID other than the described ones is issued, con-

tact our service personnel for some advice.

Table 4B13

Recognition Error ID Recognition Error Contents, Cause, and Remedy

0100100000 Error in Recognition Communication Data

(Cause) An error was found in the recognition communication data.

(Remedy 1) Contact our service personnel for details.

0121300000 "P.E.C. Lighting #2" is not Connected!

(Cause) Failed in confirmation to the connection of the lighting unit for ceramic boards.

(Remedy 1) Contact our service personnel for some advice.

0130300001 Error in "Camera MAGNIFICATION X or

MAGNIFICATION Y" Data.

(Cause) Wrong parameters are set.

(Remedy 1) Set the correct data.

4.3 Recognition Error IDs and Remedial Procedures

0509-002 2-182 AIM01ETRP
