Recognition Error ID Recognition Error Contents, Cause, and Remedy
0131300001 Error in "Camera POSITION X or POSITION Y" Data.
0131300003 Error in "Camera ANGLE" Data.
0131300007 Error in "Camera 1 – 2 X or Y" Data.
0132300002 Error in "Camera GAIN or LEVEL" Data.
0133300001 Error in "Nozzle Offset High Mag. X or Y" Data.
0133300002 Error in "Nozzle Offset Low Mag. X or Y" Data.
0133300004 Error in "Nozzle O.D.Size" Data.
0133300005 Error in "Nozzle I.D.Size" Data.
0133300008 Error in "Nozzle V-Groove Size" Data.
0134300001 Error in "Indidual Nozzle Gain or Level" Data.
0135300001 Error in "Nozzle High or Low level offset" Data.
0136300001 Error in "Nozzle Position Offset" Data.
0137300001 Error in "Head Center X or Y Offset" Data.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
4.3 Recognition Error IDs and Remedial Procedures
0509-002 2-183 AIM01ETRP
Recognition Error ID Recognition Error Contents, Cause, and Remedy
0138200000 Unavailable fiducial mark code was set.
0138200001 "Mark Size D2" is too big, compared with "D1".
0138200002 "Mark Size D3" is too big, compared with "D1".
0138200003 "Mark Size D2" is too big, comapred with"D3".
0138200004 "Window Size" is smaller than "Mark Size".
0138200005 "Mark Size D2" is not set.
0138200006 "Mark Size D3" is not set.
0138300001 Error in "P.C.B Recognition Mark Data Mark Size D1 or D2 or D3" Data.
0138300003 Error in "P.C.B Recognition Mark Data Window Size" Data.
(Cause) Wrong parameters are set for the P.E.C. recognition function.
(Remedy) Refer to "Section 2 Pattern Program" in "Vol. 3" for details and set correct
parameters.
4.3 Recognition Error IDs and Remedial Procedures
0509-002 2-184 AIM01ETRP
Recognition Error ID Recognition Error Contents, Cause, and Remedy
0139211001 An improper parameter is specified as "Component shape".
0139211002 "Mold Size Tolerance X" is larger than "Mold Size X".
0139211003 "Mold Size Tolerance Y" is larger than "Mold Size Y".
0139211004 "Outward Length Tolerances" are larger than "Outward Length".
0139211005 A front reverse side judging cannot be carried out by this component size or the
lighting pattern.
0139212001 The total of "Corner 1 Dim X" and "Corner 4 Dim X" is larger than "Mold Size X".
0139212002 The total of "Corner 1 Dim Y" and "Corner 2 Dim Y" is larger than "Mold Size Y".
0139212003 The total of "Corner 2 Dim X" and "Corner 3 Dim X" is larger than "Mold Size X".
0139212004 The total of "Corner 3 Dim Y" and "Corner 4 Dim Y" is larger than "Mold Size Y".
0139212005 "Electrode Size" is larger than half of "Mold Size X".
0139212006 # of Linear Edges is improper.
0139213001 "# of Types" (lead data) is improper.
0139213002 "# of Groups" (lead data) is improper.
0139213003 The total of "# of Leads" (lead data) is too small.
0139213004 "No Detection" is set in all "Insp Condtn" text boxes.
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
4.3 Recognition Error IDs and Remedial Procedures
0509-002 2-185 AIM01ETRP
