Section 1

Maintenance

0309-002 1-A AIM01ETRP

This section describes periodic maintenance operations,

etc., for those who are in charge of the machine mainte-

nance.

0305-001 1-B AIM01ETRP

1. Periodic Maintenance

1.1 Precautionary Items before Maintenance

This session describes how to perform inspections, cleaning, lubrica-

tion, and adjustment to keep the machine in good shape.

It is recommended that periodic maintenance of the machine should

be ensured.

1. Periodic Maintenance

0412-003 1-1 AIM01ETRP

• Only qualified personnel should perform maintenance work carefully

in compliance with the specified procedures.

• Before performing maintenance work, turn off the power and air

sources and lock the power breaker using the padlock.

If maintenance work is performed with the machine powered, a major

injury or a damage might be caused due to a malfunction of the ma-

chine or an unexpected operation by the third party.

After the end of maintenance work, be sure to attach the machine

cover.

• Designate a person who can have charge of the padlock key.

• If the provided padlock is lost or damaged, purchase its substitute.

Power Supply Section

Fig. 4A1

Air Source Section

Fig. 4A2

WARNING

Power Breake

Padlock

(630 061 9737)

Main Valve

Padlock (630 053 4917)
