4OM-1505 1-62 5. List of Consumables and Servicing Parts : Chap.1 0906-001
4OM-1505
1-61
5. List of Consumables and Servicing Parts : Chap.1
T4A14
Product/Block
Name
Product
No
Part No. Part Name Standard and Material Q’ty
Recommended
# of Years
Remarks
G
PEC
Recognition
S010 23G00111 SENSOR,
PELEC
#E3S-LS3RC4 1 3
S012 23G10056 SENSOR,
EE-SX674 3 3
S112 23G10001 SENSOR,
EE-SX670 1 3
S307 23G10056 SENSOR,
EE-SX674 2 3
S308 23G10029 SENSOR,
EE-SX672 1 3
H
Conveyor
Section
S018 23G10056 SENSOR,
EE-SX674 2 3
S029 223Q0663 PULLEY,
TIMING
#T0304-2401
(P26-2GT)
8 5
S030 223M0059 PULLEY,
FLAT
#T0304-2402 8 5
S102 23G00243 SENSOR,
PELEC
E3S-LS3NW 1 5
S107 23G00269 SENSOR,
PELEC
E3T-FD11 1 5
S202 23G00243 SENSOR,
PELEC
E3S-LS3NW 1 5
S204 23G00269 SENSOR,
PELEC
E3T-FD11 1 5
S301 223L0398 BELT,
TIMING
1GG223L003980-- 4 3
R
Cover
Section
S002 4M130044 MOTOR,DC CNDC24Z7Q 2 9
S132 222R0054 SPRING
(GUS)
30Q0 2 5
S133 222R0057 SPRING
(GUS)
30Q3 2 5
M
Cleaning
Section
S004 23G10029 SENSOR,
EE-SX672 1 3
S005 23G00146 SENSOR,
PELEC
E3T-ST11 1 3
BB
Control
Board
S103 4U240503 UNIT,
DRIVER
#RS1L03AA03501P01 1 6
S109 4U240502 UNIT,
DRIVER
#RS1L03AA03601P01 1 6
S201 4U200275
UNIT,POWER
ZWS10-12/JA 1 10
S202 4U200276
UNIT,POWER
ZWS10-24/JA 1 10
S216 4U200335
UNIT,POWER
HWS1800T-48 HFP 1 6
S401 4M130044 MOTOR,DC CNDC24Z7Q 2 9
C
Control Box
Section
S003 4U210135 UNIT,
DISPLAY
1GG4U21001350-- 1 7
0906-001
4OM-1505
1-62
5. List of Consumables and Servicing Parts : Chap.1
0906-001
4OM-1505
0906-001 2-A
Chapter 2
Troubleshooting
This chapter outlines the troubleshooting.
1. "ERROR" Window
2. Troubleshooting on Each Section
