4OM-1505
2-19
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B16
Error ID Error Name, Description, Cause, and Remedy
0411000 Stencil-Y Interlock
Table-Z Axis is not at safety area.
(Cause 1) The table Z axis interlock sensor (B4C) is defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The stencil Y axis was activated after the table Z axis had moved up. (during
the manual operation)
(Remedy 1) Check how the sensor is working in "DEVICE CHECK" window.
When the sensor is not working, it is required to replace the sensor with a
new one. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 3)
Perform the zeroing operation and restart the operation.
0414000 Stencil-Y Timing
Task has not been completed unable to continue.
0415000 Stencil-Y Data
The data was detected outside of the possible range.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
0416000 Stencil-Y Origin
Zeroing Opn. Not Complete.
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
4OM-1505
2-20
2. Troubleshooting on Each Section : Chap.2
(05 Squeegee Driving)
T4B17
Error ID Error Name, Description, Cause, and Remedy
0501000 Squeegee Drv. Origin
Zeroing opn. was incompleted, within specied time.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor (B271, B274) is defective.
(Cause 3) The
driver is malfunctioning or an error has occurred during communication with
the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the squeegee driving axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, zero the squeegee driving axis. If this operation does not reset
the machine to its normal condition, the driver may be defective. Contact our
service personnel for details.
0502000 Squeegee Drv
. Origin
Detect lost pulse error.
(Cause 1) The motor is overloaded and has a loss of synchronism.
(Remedy 1) Check for any obstacle around the squeegee driving axis and then perform
the zeroing operation. If this operation does not reset the machine to its
normal condition, contact our service personnel for details.
0504000 Squeegee Drv. Overrun
(-) Limit error has been detected.
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor (B273) is defective.
(Cause 3) The
driver is malfunctioning or an error has occurred during communication with
the host CPU.
(Remedy 1) Wipe off dirt on the sensor and zero the squeegee driving axis again.
(Remedy 2) It is required to replace the sensor with a new one. Contact our service
personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, zero the squeegee driving axis. If this operation does not reset
the machine to its normal condition, the driver may be defective. Contact our
service personnel for details.
0505000 Squeegee Drv
. Driver
Driver alarm signal was detected.
0508000 Squeegee Drv. Driver
Driver Over-Heat
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If this operation does not reset the
machine to its normal condition, contact our service personnel for details.
0906-001
4OM-1505
2-21
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B18
Error ID Error Name, Description, Cause, and Remedy
0513000 Squeegee Drv. Interlock
Front squeegee was down.
(Cause 1) The front squeegee upper limit and intermediate sensors (B60 and 61) are
defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The squeegee driving axis was activated after the front squeegee had moved
down. (during the manual operation)
(Remedy 1) Check how the sensors are working in "DEVICE CHECK" window.
When the sensors are not working, it is required to replace the sensors with
new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 3)
Perform the zeroing operation and restart the operation.
0514000 Squeegee Drv. Interlock
Rear squeegee was down.
(Cause 1) The rear squeegee upper limit and intermediate sensors (B62 and 63) are
defective.
(Cause 2) The operation timing is shifted from the normal one.
(Cause 3) The squeegee driving axis was activated after the rear squeegee had moved
down. (during the manual operation)
(Remedy 1) Check how the sensors are working in "DEVICE CHECK" window.
When the sensor are not working, it is required to replace the sensors with
new ones. Contact our service personnel for details.
(Remedy 2) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 3)
Perform the zeroing operation and restart the operation.
0515000 Squeegee Drv. Timing
Task has not been completed unable to continue.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and restart the operation. If this operation does not reset the
machine to its normal condition, contact our service personnel for details.
When the same error still occurs, contact our service personnel for details.
0516000 Squeegee Drv. Data
The data was detected outside of the possible range.
(Cause 1) The specied data may have exceeded the movable range.
(Remedy 1) Check the parameters in the "Print Margin" and "Paste Size" text boxes of the
"Printing Condition" tab sheet in "DEVICE DATA" and "Print Area" ("Pattern
Program" window).
0517000 Squeegee Drv
. Origin
Zeroing Opn. Not Complete.
(Cause 1) The motor axis was activated before the zeroing operation was completed.
(Remedy 1) Perform the zeroing operation.
