4OM-1505
2-58
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B55
Error ID Error Name, Description, Cause, and Remedy
1904038 Stencil Recog. Test
Unavailable ducial mark polality was set.
1904040 Stencil Recog. Test
Unavailable ducial mark area was set.
1904043 Stencil Recog. Test
Recognition system error.
1904056 Stencil Recog. Test
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
1906000 Stencil Recog. Camera
1906001 Stencil Recog. Camera
[Camera ID] exceeds the range of setting.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1)
Zero all axes and restart the operation. If the machine is not reset to its
normal condition, shut down the power of the machine once and power up
the machine again. After that, restart the operation. When the same error still
occurs, contact our service personnel for details.
1906003 Stencil Recog. Camera
[Camera Gain] exceeds the range of setting.
1906004
Stencil Recog. Camera
[Camera Level] exceeds the range of setting.
1906011 Stencil Recog. Camera
[Mark Size D1] exceeds the range of setting.
1906012 Stencil Recog. Camera
[Mark Size D2] exceeds the range of setting.
1906014 Stencil Recog. Camera
[Mark Judge Level] exceeds the range of setting.
(Cause 1) The data has exceeded the allowable range.
(Remedy 1) Set correct parameters.
1906029 Stencil Recog. Camera
Image around ducial mark was unstable.
1906030 Stencil Recog. Camera
Error of mark gure similitude was extensive.
1906031 Stencil Recog. Camera
Error of mark similitude or mark size was extensive.
1906032
Stencil Recog. Camera
Specied mark was not found in window of recog.monitor.
(Cause 1) The ducial marks do not conform to the coordinates X and Y of the ducial
marks or the recognition mark data in the pattern program.
(Remedy 1) Follow the steps below to reset the machine to the normal condition. Refer to
"Error ID "1901032"" for details.
4OM-1505
2-59
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B56
Error ID Error Name, Description, Cause, and Remedy
1906038 Stencil Recog. Camera
Unavailable ducial mark polality was set.
1906040 Stencil Recog. Camera
Unavailable ducial mark area was set.
1906043 Stencil Recog. Camera
Recognition system error.
1906056 Stencil Recog. Camera
Recog. transaction time over.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
4OM-1505
2-60
2. Troubleshooting on Each Section : Chap.2
(20 Cleaning)
T4B57
Error ID Error Name, Description, Cause, and Remedy
2001000 Cleaning Interlock
PEC Recog-Y Axis is not at safety area.
(Cause 1) The cleaning nozzle was moved up when the PEC recognition Y axis was
not located at its front escape position (origin position). (during the manual
operation)
(Cause 2) The PEC recognition Y-axis near origin sensor (B46) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the PEC recognition Y axis and restart the operation.
(Remedy 2)
Zero the PEC recognition Y axis. When the PEC recognition Y axis cannot
be zeroed, it is required to replace the sensor with a new one. Contact our
service personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
2005000 Cleaning
Cleaning nozzle up/down cylinder moving error.
(Cause 1) The cleaning U/D cylinder sensors (B81 and B82) did not work normally.
(Remedy 1) Check how the sensors are working while the cleaning unit is moving up and
down. When the same error still occurs, contact our service personnel for
details.
2006000 Cleaning
Cleaning paper feed error
(Cause 1) The paper feeder (take-up) pitch detection sensor (B83) is not working.
(Cause 2) The inside of the cleaning paper roller is torn, making the rotation of the paper
cylinder idle.
(Cause 3) The belt of the take-up motor is not engaged correctly (some teeth not meshing
with the belt).
(Remedy 1) Check for any dirt around the sensor and how the sensor is working in the
"DEVICE CHECK" window. When the sensor is not working, it is required to
adjust the sensor position or replace the sensor with a new one. Contact our
service personnel for details.
(Remedy 2) Check the internal condition of the paper roller. If some area is damaged,
replace it with another one.
(Remedy 3)
When you hear some sounds, indicating that some teeth do not mesh
correctly with the belt during the take-up operation, it is required to adjust the
belt tension. Contact our service personnel for details.
