4OM-1505
2-60
2. Troubleshooting on Each Section : Chap.2
(20 Cleaning)
T4B57
Error ID Error Name, Description, Cause, and Remedy
2001000 Cleaning Interlock
PEC Recog-Y Axis is not at safety area.
(Cause 1) The cleaning nozzle was moved up when the PEC recognition Y axis was
not located at its front escape position (origin position). (during the manual
operation)
(Cause 2) The PEC recognition Y-axis near origin sensor (B46) is defective.
(Cause 3) The operation timing is shifted from the normal one.
(Remedy 1) Zero the PEC recognition Y axis and restart the operation.
(Remedy 2)
Zero the PEC recognition Y axis. When the PEC recognition Y axis cannot
be zeroed, it is required to replace the sensor with a new one. Contact our
service personnel for details.
(Remedy 3) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
2005000 Cleaning
Cleaning nozzle up/down cylinder moving error.
(Cause 1) The cleaning U/D cylinder sensors (B81 and B82) did not work normally.
(Remedy 1) Check how the sensors are working while the cleaning unit is moving up and
down. When the same error still occurs, contact our service personnel for
details.
2006000 Cleaning
Cleaning paper feed error
(Cause 1) The paper feeder (take-up) pitch detection sensor (B83) is not working.
(Cause 2) The inside of the cleaning paper roller is torn, making the rotation of the paper
cylinder idle.
(Cause 3) The belt of the take-up motor is not engaged correctly (some teeth not meshing
with the belt).
(Remedy 1) Check for any dirt around the sensor and how the sensor is working in the
"DEVICE CHECK" window. When the sensor is not working, it is required to
adjust the sensor position or replace the sensor with a new one. Contact our
service personnel for details.
(Remedy 2) Check the internal condition of the paper roller. If some area is damaged,
replace it with another one.
(Remedy 3)
When you hear some sounds, indicating that some teeth do not mesh
correctly with the belt during the take-up operation, it is required to adjust the
belt tension. Contact our service personnel for details.
0906-001
4OM-1505
2-61
2. Troubleshooting on Each Section : Chap.2
(21 Operator’s Error)
T4B58
Error ID Error Name, Description, Cause, and Remedy
2102000 Illegal Operation
PCB was took on inp. conveyor.
(Cause 1) Although a manual operation cannot be implemented with a PCB on the input
conveyor, such an operation was performed with a PCB.
(Remedy 1) Remove the PCB on the input conveyor and restart the operation.
2103000 Illegal Operation
PCB removed from input conveyor.
(Cause 1) Although a manual operation cannot be implemented without a PCB on the
input conveyor, such an operation was performed without a PCB.
(Remedy 1)
Place a PCB on an area of the input conveyor where the sensor reacts.
2105000 Illegal Operation
Current program was not identied. Please select program data.
(Cause 1) The automatic or the manual operation was performed without any pattern
program specied as a current one.
(Remedy 1) Perform a program change operation.
2106000 Illegal Operation
PCB was took on table.
(Cause 1) Although a manual operation cannot be implemented with a PCB on the table,
such an operation was performed with a PCB.
(Remedy 1) Remove the PCB on the table and restart the operation. Click the table
section (illustrated) in the "AUTO OPN." window to remove the PCB from the
memory of the machine whenever necessary.
2107000 Illegal Operation
PCB removed from table.
(Cause 1) Although a manual operation cannot be implemented without a PCB on the
table, such an operation was performed without a PCB.
(Remedy 1) Place a PCB on the table and restart the operation. Click the table section
(illustrated) in the "AUT
O OPN." window to set the PCB in the memory of the
machine whenever necessary.
2108000 Illegal Operation
PCB was took on output conveyor
.
(Cause 1) Although a manual operation cannot be implemented with a PCB on the output
conveyor, such an operation was performed with a PCB.
(Remedy 1) Remove the PCB on the output conveyor and restart the operation.
2109000 Illegal Operation
PCB removed from output conveyor.
(Cause 1) Although a manual operation cannot be implemented with a PCB on the output
conveyor, such an operation was performed with a PCB.
(Remedy 1) Place a PCB on an area of the output conveyor where the sensor reacts.
0906-001
4OM-1505
2-62
2. Troubleshooting on Each Section : Chap.2
0906-001
T4B59
Error ID Error Name, Description, Cause, and Remedy
2113000 Illegal Operation
Vacuum cleaning can not use in vacuum plate chuck on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A cleaning suction operation was performed during the vacuum cleaning (chuck
suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 2) Cancel the cleaning suction operation through the manual operation and
restart the operation.
2114000 Illegal Operation
Vacuum plate can not use at vacuum cleaning on.
(Cause 1) The operation timing is shifted from the normal one.
(Cause 2) A
chuck suction operation was performed during the vacuum cleaning (chuck
suction). (during the manual operation)
(Remedy 1) Shut down the power of the machine once and power up the machine again.
After that, restart the operation. When the same error still occurs, contact our
service personnel for details.
(Remedy 2) Cancel the cleaning suction operation through the manual operation and
restart the operation.
2115000 Illegal Operation
Input conveyor width was out of specied range.
2116000
Illegal Operation
Table chute width was out of specied range.
2117000 Illegal Operation
Output conveyor width was out of specied range.
(Cause 1) The PCB dimension (Y) in the current pattern program differs extremely from
the input conveyor width.
(Remedy 1) Open the "COLLCTVE. SETUP" window and change the conveyor width.
2118000 Illegal Operation
Stencil recog. was not nished.
(Cause 1) An operation was performed to check the results of the stencil recognition
although no stencil recognition operation is performed yet.
(Remedy 1) Perform the stencil recognition.
