4OM-1505 1-9 1. Outline of Maintenance : Chap.1 Device Name Inspection, Cleaning, and Lubricating Spots Work Maintenance Cycle Daily Weekly Monthly Every 3 Months Every 6 Months 5 Y ears 3.2.9 T ransparent Cover Section …
4OM-1505
1-8
1. Outline of Maintenance : Chap.1
0906-001
Device Name
Inspection, Cleaning, and
Lubricating Spots
Work
Maintenance Cycle
Daily
Weekly
Monthly
Every 3
Months
Every 6
Months
5 Years
3.2.6
PCB Chuck Section
Upper Surface of PCB
Transfer Belt
Cleaning
PCB Positioning Side and
Upper Surface
Cleaning
Upper Surface and Pin Hole
Section of Backup Table
Cleaning
Backup Table Z-Axis
Guide Bushing
Cleaning
Lubrication
Linear Guide for Chute
Width Adjustment
(Left Side), (Right Side)
Cleaning
Lubrication
Linear Guide for
PCB Clamping
Cleaning
Lubrication
Trapezoid Screw for
Chute Width Change
(Left Side), (Right Side)
Lubrication
Backup Table Z-Axis
Ball Screw
Lubrication
3.2.7
Table Section
Table X-Axis Linear Guide
(Front Left Side),
(Front Right Side),
(Rear Side)
Cleaning
Lubrication
Table Z-Axis
Guide Bushing
Cleaning
Lubrication
Table θ-Axis Linear Guide Cleaning
Lubrication
Table θ-Axis Movable
Bearing Outer
Circumference
Cleaning
*
Table X-Axis Ball Screw
Lubrication
Table Z-Axis Ball Screw
Lubrication
Table θ-Axis Ball Screw
Lubrication
3.2.8
Cleaning Section
Hose and Hose Joint Check,
Cleaning
Solvent Tank, Solvent Pan,
and Hose Joint
Check,
Cleaning
4OM-1505
1-9
1. Outline of Maintenance : Chap.1
Device Name
Inspection, Cleaning, and
Lubricating Spots
Work
Maintenance Cycle
Daily
Weekly
Monthly
Every 3
Months
Every 6
Months
5 Years
3.2.9
Transparent Cover Section
Front Transparent Cover
Hinge Part
Lubrication
Rear Transparent Cover
Hinge Part
Lubrication
Gas Damper (Four Places)
Lubrication
3.2.10
Blower Unit
Vacuum Filter Cleaning
0906-001
4OM-1505
1-10
2. Maintenance Check List : Chap.1
2. Maintenance Check List
The periodic maintenance items (inspection, cleaning, lubrication, etc.) are
classied and described based on how frequently each item should be performed.
Use the tables below as check lists.
2.1 Daily Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Tools Check
3.2.2
Squeegee Head
Section
Squeegee Cleaning - Rag and Industrial Alcohol
(Solvent)
3.2.3
Stencil Holder Section
Stencil Printing Pattern Cleaning - Industrial Alcohol
(Solvent) and Ultrasonic
Cleaning
Upper Surface of Stencil
Holder
Cleaning - Rag
Lower Surface of Stencil Cleaning - Rag and Industrial Alcohol
(Solvent)
3.2.5
Conveyor Section
L conveyor Upper Surface
of PCB Transfer Belt
Cleaning - Vacuum Cleaner
R conveyor Upper Surface
of PCB Transfer Belt
Cleaning - Vacuum Cleaner
3.2.6
PCB Chuck Section
Upper Surface of PCB
Transfer Belt
Cleaning - Vacuum Cleaner
PCB Positioning Side and
Upper Surface
Cleaning - Vacuum Cleaner
3.2.8
Cleaning Section
Hose and Hose Joint Liquid
Leakage
Check,
Cleaning
- Rag
Solvent Tank, Solvent
Pan, and Hose Joint
Liquid
Leakage
Check,
Cleaning
- Rag
