4OM-1505
1-13
2. Maintenance Check List : Chap.1
2.3 Monthly Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Tools Check
3.2.2
Squeegee Head
Section
Recognition Lighting
Glass Surface
Cleaning - Air Blow Brush for
Camera
Squeegeee Head
Y-Axis Linear Guide
(Left Side), (Right Side)
Cleaning - Oiled Rag
Stencil Recognition
X-Axis Linear Guide
Cleaning - Oiled Rag
Guide Bushing for
Squeegee Up/Down
Movement
Cleaning - Oiled Rag
3.2.3
Stencil Holder Section
Stencil Y-Axis
Linear Guide
Cleaning - Oiled Rag
3.2.4
PEC Recognition
Section
Recognition Lighting
Glass Surface
Cleaning - Air Blow Brush for
Camera
X-Axis Linear Guide Cleaning - Oiled Rag
Y-Axis Linear Guide Cleaning - Oiled Rag
3.2.5
Conveyor Section
Linear Guide for L
Conveyor Width Change
Cleaning - Oiled Rag
Linear Guide for R
Conveyor Width Change
Cleaning - Oiled Rag
3.2.6
PCB Chuck Section
Backup Table Z-Axis
Guide Bushing
Cleaning - Oiled Rag
Linear Guide for Chute
Width Adjustment
(Left Side), (Right Side)
Cleaning - Oiled Rag
Linear Guide for
PCB Clamping
Cleaning - Oiled Rag
3.2.7
Table Section
Table X-Axis
Linear Guide
Cleaning - Oiled Rag
Table Z-Axis
Guide Bushing
Cleaning - Oiled Rag
Table θ-Axis
Linear Guide
Cleaning - Oiled Rag
3.2.8
Cleaning Section
Cleaning Nozzle Cleaning - SOLMIX
Rag
T4A8
0906-001
4OM-1505
1-14
2. Maintenance Check List : Chap.1
2.4 Quarterly Maintenance
Grease Symbols
NM1 : MOLYNOC GREASE AP1
Notice
Lubrication must be made on the *-marked items after initial month and
every 3 months for the subsequent use.
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Tools Check
3.2.7
Table Section
Table θ-Axis Movable
Bearing Outer
Circumference
Lubrication
NM1 Brush and Spatula
T4A9
0906-001
4OM-1505
1-15
2. Maintenance Check List : Chap.1
2.5 Quarterly Maintenance
Grease Symbols
DE1: DAPHNE EPONEX GREASE No. 1
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Tools Check
3.2.2
Squeegee Head
Section
Squeegee Head Y-Axis
Ball Screw
Lubrication
DE1 Brush and Spatula
Guide Bushing for
Squeegee Up/Down
Movement
Lubrication
DE1 Brush and Spatula
Stencil Recognition
X-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
3.2.3
Stencil Holder Section
Stencil Y-Axis Ball Screw
Lubrication
DE1 Brush
3.2.4
PEC Recognition
Section
PCB Stopper Guide
Bushing
Lubrication
DE1 Brush and Spatula
PEC Recognition
X-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
PEC Recognition
Y-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
3.2.6
PCB Chuck Section
Backup Table Z-Axis
Guide Bushing
Lubrication
DE1 Brush and Spatula
Backup Table Z-Axis Ball
Screw
Lubrication
DE1 Brush and Spatula
Trapezoid Screw for Chute
Width Change
(Left Side), (Right Side)
Lubrication
DE1 Brush and Spatula
3.2.7
Table Section
Table X-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
Table Z-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
Table Z-Axis
Guide Bushing
Lubrication
DE1 Brush and Spatula
Table θ-Axis Ball Screw
Lubrication
DE1 Brush and Spatula
3.2.9
Transparent Cover
Section
Front Transparent Cover
Hinge Part
Lubrication
DE1 Brush
Rear Transparent Cover
Hinge Part
Lubrication
DE1 Brush
Gas Damper (Four Places)
Lubrication
DE1 Brush, Grease Gun, and
P Type
3.2.10
Blower Unit
Vacuum Filter Cleaning - Air Gun and
Vacuum Cleaner
T4A10
0906-001
