XP Proper Data List V1.40 14/11/2002 Item XP141 XP241 XP341 Description Reboot G_PlusLimit = 4.5 0 0 G-axis servo stroke (mm) Calibrated data l G_MinusLimit = -10.8 0 0 G-axis servo stroke (mm) Calibrated data l T_PlusLi…
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
__UseMicroTray
=
0
0
0
Use micro-tray 0: Do not use 1: Use
User can edit
__SetDetectCensorSW = 0 0 0
0: The machine does not have tape retainer raised detection sensor 1: tape retainer raised check double sensors
are installed
User cannot edit
l
_EjectPanelUncondition = 0 0 0
During the panel unloading process if the board request signal from the next machine turns off when the panel is
passing the Main or Out pass through check sensor, 0 = stop with error, 1 = continue the panel unloading process.
User can edit
_________CYCLE_STEAL________
0
0
0
__CycleStealStartTime
=
5
5
5
The cycle steal check interval (minutes). Set to 0 to bypass the cycle steal.
User can edit
__CycleStealTerm
=
10
10
10
The cycle steal threshold. If the heat expansion is more than this value then the cycle steal is carried out. [um]
User can edit
_________AUTO_SETUP________
=
0
0
0
__ASSMCNum
=
0
0
0
Auto changeover flag. Enter numbers of M/Cs for together changeover for each group (1~3).
User can edit
l
__MCComPort
=
10000
10000
10000
Auto changeover flag. Port No. for the G-lead machine & other machines connection.(100000~99999)
User can edit
l
__PCComPort
=
10000
10000
10000
Auto changeover flag. Port No. for G-lead machine & IJ process connection (100000 ~ 99999) Specify only G-lead m/c
User can edit
l
__ASSFeederChk
=
0
0
0
Auto changeover flag. Feeder setup check 0:used. 1:Check only changed slot. 2: Check all slots.
User can edit
l
__ASSFeederChkAllSet
=
0
0
0
Auto changeover flag. Display [All OK] during feeder set up check 0: not display 1: display
User can edit
l
__ASSetupInfoDisp
=
0
0
0
Auto changeover flag. Display "Setup Information" dialog during changeover 0: not display 1: display
User can edit
l
_________DEBUG_FLAG________
=
0
0
0
__DebugFlag1
=
0
0
0
Debug flag
User cannot edit
__DebugFlag2
=
0
0
0
Debug flag
User cannot edit
__DebugFlag3
=
0
0
0
Debug flag
User cannot edit
__DebugFlag4
=
0
0
0
Debug flag
User cannot edit
__DebugFlag5
=
0
0
0
Debug flag
User cannot edit
__DebugFlag6
=
0
0
0
Debug flag
User cannot edit
__DebugFlag7
=
0
0
0
Debug flag
User cannot edit
__DebugFlag8
=
0
0
0
Debug flag
User cannot edit
__DebugFlag9
=
0
0
0
Debug flag
User cannot edit
__DebugFlag10
=
0
0
0
Debug flag
User cannot edit
__DebugBP = 0 0 0
Debug proper data for the threshold measurement: Switching the panel display at the threshold measurement.
0: Do not display during threshold measurement
1: Display the result of the measured threshold value in green at threshold measurement
2: Display the measuring range in green at threshold measurement
3: Display the result of the measured threshold value and the measuring range in green at threshold measurement
User cannot edit
__DebugDLL
=
0
0
0
*2 Display "Dynamic Logical Level" in green (LL level is figured up automatically) [T1.12c]
User cannot edit
__DebugBML
=
0
0
0
*3 Display "BlackMaskLevel" in yellow. [T1.12c]
User cannot edit
__CStructCheck
=
0
0
0
Overwrite protection (Illegal overwrite) of software configuration ("1" to ON)
User cannot edit
l
__NotPartLevel
=
0
0
0
Setting for fiducial mark vision process 0: Level 1: differential calculus
User cannot edit
l
_____CONV_DELAY_TIMER______
=
0
0
0
__InArrvOnDelayTimer
=
10
10
10
Delay timer setting for IN arrival check sensor ON [msec]
User can edit
__MainDecOnDelayTimer
=
10
10
10
Delay timer setting for MAIN deceleration sensor ON [msec]
User can edit
__MainArrvOnDelayTimer
=
10
10
10
Delay timer setting for MAIN arrival check sensor ON [msec]
User can edit
__MainPassOnDelayTimer
=
10
10
10
Delay timer setting for MAIN pass through check sensor ON [msec]
User can edit
__OutPassOnDelayTimer
=
10
10
10
Delay timer setting for OUT pass through check sensor ON [msec]
User can edit
_________TOUCH_PANEL_______
=
0
0
0
__TouchPanelType
=
1
1
1
[0:Touch panel is NOT used 1:Used]
User cannot edit
__TPDblClickSpeed
=
350
350
350
Mouse double click speed (msec)
User cannot edit
__TPDblClickDistance
=
30
30
30
Double click area
User cannot edit
_________SERVO_LIMIT_______
=
0
0
0
X_PlusLimit
=
835
835
835
X-axis servo stroke (mm)
Calibrated data l
X_MinusLimit
=
0
0
0
X-axis servo stroke (mm)
Calibrated data l
Y_PlusLimit
=
813
1174
834
Y-axis servo stroke (mm)
Calibrated data l
Y_MinusLimit
=
0
0
0
Y-axis servo stroke (mm)
Calibrated data l
Z_PlusLimit
=
14.5
55
55
Z-axis servo stroke (mm)
Calibrated data l
Z_MinusLimit
=
0
0
0
Z-axis servo stroke (mm)
Calibrated data l
F_PlusLimit
=
4.5
0
0
F-axis servo stroke (mm)
Calibrated data l
F_MinusLimit
=
-10.8
0
0
F-axis servo stroke (mm)
Calibrated data l
3/10
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
G_PlusLimit
=
4.5
0
0
G-axis servo stroke (mm)
Calibrated data l
G_MinusLimit
=
-10.8
0
0
G-axis servo stroke (mm)
Calibrated data l
T_PlusLimit
=
0
520
0
T-axis servo stroke (mm)
Calibrated data l
T_MinusLimit
=
0
0
0
T-axis servo stroke (mm)
Calibrated data l
U_PlusLimit
=
0
532
0
U-axis servo stroke (mm)
Calibrated data l
U_MinusLimit
=
0
0
0
U-axis servo stroke (mm)
Calibrated data l
_______JOG_BASE_SPEED______
=
0
0
0
X_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
Y_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
Z_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
Q_jogBaseSpeed
=
50000
50000
50000
Base inching speed (logical pulse/sec)
User cannot edit
R_jogBaseSpeed
=
50000
50000
50000
Base inching speed (logical pulse/sec)
User cannot edit
F_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
G_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
T_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
U_jogBaseSpeed
=
10000
10000
10000
Base inching speed (logical pulse/sec)
User cannot edit
______SERVO_PARAMETER______
=
0
0
0
x_MaxV
=
16000000
16000000
16000000
X-axis Max. speed
User cannot edit
x_MaxA
=
240000000
230000000
230000000
X-axis Max acceleration
User cannot edit
x_ptpGain
=
100
100
100
X-axis Gain value during traveling
User cannot edit
x_stGain
=
500
250
250
X-axis Gain value during positioning
User cannot edit
x_afterGain
=
60
100
60
X-axis Gain value during stopping
User cannot edit
x_P_CON_Start
=
6
6
6
X-axis P_CON start time (ms)
User cannot edit
x_integralGain
=
60
100
100
X-axis Integral gain
User cannot edit
x_AxisValid
=
1
1
1
X-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
x_spare2
=
1
1
1
X-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
x_CurveNo
=
1
1
1
X-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
y_MaxV
=
25000000
25000000
25000000
Y-axis Max. speed
User cannot edit
y_MaxA
=
372000000
448000000
448000000
Y-axis Max acceleration
User cannot edit
y_ptpGain =
Steel pulley
110
Aluminium pulley
100
150 150 Y-axis Gain value during traveling
User cannot edit
y_stGain =
Iron pulley
650
Aluminum pulley
1000
500 500 Y-axis Gain value during positioning
User cannot edit
y_afterGain
=
60
120
150
Y-axis Gain value during stopping
User cannot edit
y_P_CON_Start
=
6
6
6
Y-axis P_CON start time (ms).
User cannot edit
y_integralGain
=
60
120
150
Y-axis Integral gain
User cannot edit
y_AxisValid
=
1
1
1
Y-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
y_spare2
=
1
1
1
Y-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
y_CurveNo
=
1
1
1
Y-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
z_MaxV
=
7040000
10000000
10000000
Z-axis Max. speed
User cannot edit
z_MaxA
=
1500000000
830000000
830000000
Z-axis Max acceleration
User cannot edit
z_ptpGain
=
T1.16b ~ =160
~ T1.13 =200
200 200 Z-axis Gain value during traveling
User cannot edit
z_stGain
=
T1.16b ~ =3000
~ T1.13 =4000
1000 1000 Z-axis Gain value during positioning
User cannot edit
z_afterGain
=
150
150
150
Z-axis Gain value during stopping
User cannot edit
z_P_CON_Start
=
6
6
6
Z-axis P_CON start time (ms)
User cannot edit
z_integralGain
=
150
150
150
Z-axis Integral gain
User cannot edit
z_AxisValid
=
1
1
1
Z-axis 1: Valid this axis 0: Ignore this axis
User cannot edit
z_spare2
=
1
1
1
Z-axis 1:Valid this axis 0: Ignore this axis
User cannot edit
4/10
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
z_CurveNo
=
1
1
1
Z-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
q_MaxV
=
210000000
210000000
210000000
?-axis Max. speed
User cannot edit
q_MaxA
=
13000000000
10000000000
10000000000
?-axis Max acceleration
User cannot edit
q_ptpGain
=
200
300
300
?-axis Gain value during traveling
User cannot edit
q_stGain
=
500
2000
2000
?-axis Gain value during positioning
User cannot edit
q_afterGain
=
100
200
200
?-axis Gain value during stopping
User cannot edit
q_P_CON_Start
=
6
6
6
?-axis P_CON start time (ms).
User cannot edit
q_integralGain
=
100
200
200
?-axis Integral gain
User cannot edit
q_AxisValid
=
1
1
1
?-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
q_spare2
=
1
1
1
?-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
q_CurveNo
=
1
1
1
?-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
r_MaxV
=
105000000
0
0
R-axis Max. speed
User cannot edit
r_MaxA
=
12000000000
0
0
R-axis Max acceleration
User cannot edit
r_ptpGain
=
120
0
0
R-axis Gain value during traveling
User cannot edit
r_stGain
=
1000
0
0
R-axis Gain value during positioning
User cannot edit
r_afterGain
=
100
0
0
R-axis Gain value during stopping
User cannot edit
r_P_CON_Start
=
6
0
0
R-axis P_CON start time (ms).
User cannot edit
r_integralGain
=
60
0
0
R-axis Integral gain
User cannot edit
r_AxisValid
=
1
0
0
R-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
r_spare2
=
1
0
0
R-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
r_CurveNo
=
3
0
0
R-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
f_MaxV
=
8500000
0
0
F-axis Max. speed
User cannot edit
f_MaxA
=
1900000000
0
0
F-axis Max acceleration
User cannot edit
f_ptpGain
=
200
0
0
F-axis Gain value during traveling
User cannot edit
f_stGain
=
2000
0
0
F-axis Gain value during positioning
User cannot edit
f_afterGain
=
150
0
0
F-axis Gain value during stopping
User cannot edit
f_P_CON_Start
=
6
0
0
F-axis P_CON start time (ms)
User cannot edit
f_integralGain
=
100
0
0
F-axis Integral gain
User cannot edit
f_AxisValid
=
1
0
0
F-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
f_spare2
=
1
0
0
F-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
f_CurveNo
=
1
0
0
F-axis Cam curve No.(1:sinusoidal transformation, 3:NC2etc)
User cannot edit
g_MaxV
=
8500000
0
0
G-axis Max. speed
User cannot edit
g_MaxA
=
1900000000
0
0
G-axis Max acceleration
User cannot edit
g_ptpGain
=
200
0
0
G-axis Gain value during traveling
User cannot edit
g_stGain
=
2000
0
0
G-axis Gain value during positioning
User cannot edit
g_afterGain
=
150
0
0
G-axis Gain value during stopping
User cannot edit
g_P_CON_Start
=
6
0
0
G-axis P_CON start time (ms)
User cannot edit
g_integralGain
=
100
0
0
G-axis Integral gain
User cannot edit
g_AxisValid
=
1
0
0
G-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
g_spare2
=
1
0
0
G-axis 1:Valid this axis 0:Ignore this axis
User cannot edit
g_CurveNo
=
1
0
0
G-axis Cam curve No. (1:sinusoidal transformation, 3:NC2etc)
User cannot edit
t_MaxV
=
0
5000000
0
T-axis Max. speed
User cannot edit
t_MaxA
=
0
100000000
0
T-axis Max acceleration
User cannot edit
t_ptpGain
=
0
50
0
T-axis Gain value during traveling
User cannot edit
t_stGain
=
0
1000
0
T-axis Gain value during positioning
User cannot edit
t_afterGain
=
0
50
0
T-axis Gain value during stopping
User cannot edit
t_P_CON_Start
=
0
6
0
T-axis P_CON start time (ms)
User cannot edit
t_integralGain
=
0
50
0
T-axis Integral gain
User cannot edit
t_AxisValid
=
0
1
0
T-axis 1: Valid this axis 0:Ignore this axis
User cannot edit
t_spare2
=
0
1
0
T-axis 1: Valid this axis 0:Ignore this axis
User cannot edit
t_CurveNo
=
0
2
0
T-axis Cam curve No.(1:sinusoidal transformation,NC2etc)
User cannot edit
u_MaxV
=
0
15000000
0
U-axis Max. speed (1500000 is the default value for the modified MTU, for the old type the value should be 100000000)
User cannot edit
u_MaxA
=
0
70000000
0
U-axis Max acceleration (70000000 is the default value for the modified MTU, for the old type the value should be 100000000)
User cannot edit
u_ptpGain
=
0
100
0
U-axis Gain value during traveling
User cannot edit
5/10
