XP Proper Data List V1.40 14/11/2002 Item XP141 XP241 XP341 Description Reboot Z_Nzl3PickUpOfst = 0 0 0 XP141 pickup offset Z for nozzle 3 (mm) Calibrated data Z_Nzl4PickUpOfst = 0 0 0 XP141 pickup offset Z for nozzle 4 …
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
______NOZZLE_DIAMETER______
=
0
0
0
__Nzl1Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl2Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl3Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl4Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl5Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl6Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl7Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl8Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl9Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl10Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl11Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
__Nzl12Diameter
=
0
0
0
Diameter of pickup nozzle (mm)
User cannot edit
_______GLASS_QF_VALUE______
=
0
0
0
__GlassQfLeadQty1
=
0
27
27
Number of leads per one side of glass gauge QF
User cannot edit
l
__GlassQfLeadWidth1
=
0
0.25
0.25
Glass gauge QF lead width
User cannot edit
l
__GlassQfLeadLen1
=
0
1.5
1.5
Glass gauge QF lead length
User cannot edit
l
__GlassQfPitch1
=
0
0.5
0.5
Glass gauge QF lead pitch
User cannot edit
l
__GlassQfDistance1
=
0
19
19
Glass gauge QF per one side length
User cannot edit
l
__GlassCircleDiameter1
=
0
2
2
Diameter of glass parts circle mark
User cannot edit
l
__GlassCircleDistance1
=
0
12.94
12.94
Distance between the center of glass circle marks
User cannot edit
l
__GlassCentCircleDiameter1
=
0
5.05
5.05
Diameter of glass gauge QF center circle
User cannot edit
l
__GlassQfLeadQty2
=
0
0
0
No. of leads per one side of glass gauge QF
User cannot edit
l
__GlassQfLeadWidth2
=
0
0
0
Glass gauge QF lead width
User cannot edit
l
__GlassQfLeadLen2
=
0
0
0
Glass gauge QF lead length
User cannot edit
l
__GlassQfPitch2
=
0
0
0
Glass gauge QF lead pitch
User cannot edit
l
__GlassQfDistance2
=
0
0
0
Glass gauge QF per one side length
User cannot edit
l
__GlassCircleDiameter2
=
0
0
0
Diameter of glass gauge QF center circle
User cannot edit
l
__GlassCircleDistance2
=
0
0
0
Distance between the center of glass circle marks
User cannot edit
l
__GlassCentCircleDiameter2
=
0
0
0
Diameter of glass gauge QF center circle
User cannot edit
l
__GlassLogicalLevel
=
0
-1500
-1500
Logical brightness level when the present glass parts is vision processed (-25500~25500) 0= impossible to carry out vision processing
User cannot edit
l
_____MATRIX_TABLE___
0
0
0
_MtxTblPitch
=
7
7
7
Mark Pitch (mm)
User cannot edit
_MtxTblX
=
65
65
65
Numbers of the measurement in the X direction
User cannot edit
_MtxTblY
=
45
45
45
Numbers of the measurement in the Y direction
User cannot edit
_MtxTblElegance
=
0.1
0.1
0.1
Elegance Value
User cannot edit
_MtxTblWaitTime1
=
30
30
30
Waiting time after servo movement completion [msec]
User cannot edit
_MtxTblWaitTime2
=
150
150
150
Waiting time for lamp to turn ON [msec]
User cannot edit
_______NOZZLE_TYPE______
=
0
0
0
_Nzl1Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl2Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl3Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl4Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl5Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl6Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl7Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl8Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl9Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl10Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl11Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
_Nzl12Type
=
0
0
0
Nozzle type 0: Standard 1: Mechanical Chuck 2: Custom
User cannot edit
____PICKUP_OFFSET_______
=
0
0
0
Z_Nzl1PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 1 (mm)
Calibrated data
Z_Nzl2PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 2 (mm)
Calibrated data
8/10
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
Z_Nzl3PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 3 (mm)
Calibrated data
Z_Nzl4PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 4 (mm)
Calibrated data
Z_Nzl5PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 5 (mm)
Calibrated data
Z_Nzl6PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 6 (mm)
Calibrated data
Z_Nzl7PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 7 (mm)
Calibrated data
Z_Nzl8PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 8 (mm)
Calibrated data
Z_Nzl9PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 9 (mm)
Calibrated data
Z_Nzl10PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 10 (mm)
Calibrated data
Z_Nzl11PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 11 (mm)
Calibrated data
Z_Nzl12PickUpOfst
=
0
0
0
XP141 pickup offset Z for nozzle 12 (mm)
Calibrated data
__________BLACK_MASK_LEVEL___________
=
0
0
0
__BMLReturnRatio
=
100
100
100
Black mask brightness ratio. When the brightness is less than Black Mask Level, how much % of the Black mask is convert into brightness. (%). User cannot edit
__BMLSide1Nzl1
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl2
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl3
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl4
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl5
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl6
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl7
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl8
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl9
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl10
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl11
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide1Nzl12
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl1
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl2
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl3
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl4
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl5
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl6
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl7
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl8
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl9
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl10
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl11
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__BMLSide2Nzl12
=
0
0
0
The nozzle Black Mask Level (Use this when the proper data "__BlackMaskLevel" is set to "-1". )
User cannot edit
__________OTHERS___________
=
0
0
0
X_MeasureFidMark
=
117.5
137.1
137.1
X-coordinates of major fiducial mark (Reference conveyor rail mark)
Calibrated data
Y_MeasureFidMark
=
209.05
207.75
211.75
Y-coordinates of major fiducial mark (Reference conveyor rail mark)
Calibrated data
__ConvWidthMtrSpeed
=
0.008
0.008
0.008
Conveyor width change speed [mm]/[msec]
Calibrated data
__ConvWidthOffset
=
0
0
0
Offset value of conveyor width when adjusting the conveyor width [mm]
Calibrated data
__ConvWidthMarkDiffX
=
0
-4.4
-4.4
Offset for difference in X-direction between reference mark and adjustable rail mark [mm]
Calibrated data
__ConvMainArrvStopDis
=
20
20
20
The distance of MAIN arrival check sensor to the stopper. [mm] (Inputting range 20 or grater)
User can edit
__DLLRatio
=
0
0
0
DLL multiply ratio when DLL value is auto-calibrated (in a case 0, it is 0.63)
User cannot edit
__VT231LLRatio
=
0
0
0
Fine adjust the LL level during processing VisionType=231(White BGA) [Range 0, 0.7 - 2.0] [T1.12c]
User cannot edit
X_CoplanarityPosX
=
0
0
0
Coplanarity check position X
User cannot edit
Y_CoplanarityPosY
=
0
0
0
Coplanarity check position Y
User cannot edit
Z_CoplanarityPosZ
=
0
0
0
Coplanarity check position Z
User cannot edit
__CoplaCamShutterSpeed
=
0
0
0
Coplanarity camera shutter speed setting (µs) *Also, change the camera SW setting
User cannot edit
__MarkAreaTolerance
=
0
0
0
Tolerance of F-mark reading area (mm)
User can edit
__MarkPitchTolerance
=
0
0
0
Tolerance of F-mark read pitch (mm)
User can edit
__DesEndDistanceFromDownEnd
=
0
0
0
Not used at present
User cannot edit
__PickPosMeasureOfstX1
=
-0.1
0
0
Enter the difference of the mark camera pickup offset and actual pickup offset at the pickup position measurement.
User can edit
__PickPosMeasureOfstY1
=
-0.05
0
0
Enter the difference of the mark camera pickup offset and actual pickup offset at the pickup position measurement.
User can edit
9/10
XP Proper Data List V1.40
14/11/2002
Item
XP141
XP241
XP341
Description
Reboot
__PickPosMeasureOfstX2
=
-0.1
0
0
Enter the difference of the mark camera pickup offset and actual pickup offset at the pickup position measurement.
User can edit
__PickPosMeasureOfstY2
=
-0.05
0
0
Enter the difference of the mark camera pickup offset and actual pickup offset at the pickup position measurement.
User can edit
__MechaChuckClampTimer
=
0
100
100
Mechanical chuck close limit waiting timer. [msec]
User can edit
__MechaChuckUnclampTimer
=
0
100
100
Mechanical chuck open limit waiting timer [msec]
User can edit
__MechaChuckSafeguard
=
0
1
1
Parts remain check for mechanical check after the placement * White paint around the mark [T1.13]
User cannot edit
l
__MechaChuckMarkDiameter
=
0
1.2
1.2
Parts remain check for mechanical check after the placement * White paint around the mark [T1.13]
User cannot edit
l
__FiducialLampSetting
=
0
0
0
0: Normal setting 1: Center light source is not used [T1.13]
User can edit
__MinimumConveyorWidth
=
0
0
0
Supports the board size Y: 50mm or less [Valid input range: 0.00 to 49.99 [mm] (Allow the entry only to the modified machine)
User cannot edit
________NOZZLE_NAME_________
=
__NzlName1
=
Special nozzle name
User cannot edit
__NzlName2
=
Special nozzle name
User cannot edit
__NzlName3
=
Special nozzle name
User cannot edit
__NzlName4
=
Special nozzle name
User cannot edit
__NzlName5
=
Special nozzle name
User cannot edit
__NzlName6
=
Special nozzle name
User cannot edit
__NzlName7
=
Special nozzle name
User cannot edit
__NzlName8
=
Special nozzle name
User cannot edit
__NzlName9
=
Special nozzle name
User cannot edit
__NzlName10
=
Special Nozzle Name
User cannot edit
__NzlName11
=
Special Nozzle Name
User cannot edit
__NzlName12
=
Special Nozzle Name
User cannot edit
_______COMMUNICATION________
=
__PCIpAdr
=
Network IP address where Wftpd32.exe is installed
User can edit
__PCUserName
=
User name set in Wftpd32.exe
User can edit
__PCPassword
=
Password set in Wftpd32.exe
User can edit
__MC01IpAdr
=
ASSystem=1 (in used) IP address of lead machine. In a case, enter same group machine IP address when it is lead machine,.
User cannot edit
__MC02IpAdr
=
ASSystem=1 (in used) Enter IP address in a same group M/Cs. (Not necessary other than lead machine)
User cannot edit
__MCNickName
=
Proper name for this machine
User can edit
10/10
