acceleration rate to improve the chances of picking up the parts gage ceramic chips.
Once the parts gage is picked up check that it is replaced in the parts gage cavity and is
not overhanging the lip of the cavity.
3. Now [Rotate Center Measurement] can be performed and the camera distance that you
have input manually will be overwritten with more accurate data taken from the vision
processing.
4. Camera Distance proper data can be found in [Maintenance C] – [Proper Data Editor] –
[Camera Offset] – [Camera1DistanceX] and [Camera1DistanceY]. Check the proper data
list for the default values.
