MIL-STD-883F

METHOD 2017.8

18 June 2004

e. Exclusions

. Where conditional exclusions have been allowed, specific instruction as to the location and conditions

for which the exclusion can be applied shall be documented in the assembly inspection drawing.

f. Definitions

(1) Active circuit area

includes all areas of functional circuit elements, operating metallization or connected

combinations thereof excluding beam leads.

(2) Add-on substrate

is a supporting structural material into and/or upon which glassivation, metallization and

circuit elements are placed and the entire assembly is in turn placed on, and attached to the main substrate.

(3) Attachment media

is defined as the material used to effect the attachment of an element to an underlying

surface (e.g., adhesive, solder, alloy).

(4) Bonding site

is a metallized area on a substrate or element intended for a wire or ribbon interconnecting bond.

(5) Cold solder joint

is defined as a solder joint whose appearance is "grainy" or "dull". Where a "grainy" or "dull"

appearance is characteristic of certain solder materials (e.g., AuSn, etc.), this criteria shall not be rejectable for

these materials.

(6) Compound bond

is one bond on top of another.

(7) Conductive attach

is the process and materials used for the attachment that also provides an electrical contact

or thermal dissipation path (e.g., solder, eutectic, solder-impregnated epoxy).

(8) Dielectric attach

is the process and materials used for attachment that does not provide electrical contact or

thermal dissipation considerations.

(9) Edge metallization

is the metallization that electrically connects the metallization from the top surface to the

opposite side of the substrate; also called wrap around metallization.

(10) Element

is a constituent of a hybrid microcircuit; such as integral deposited or screened passive elements,

substrates, discrete or integrated electronic parts including dice, chips and other microcomponents; also

mechanical piece parts as cases and covers; all contributing to the operation of a hybrid microcircuit.

(11) Electrically common

is satisfied when two or more conductive surfaces or interconnects are of equal DC

voltage/signal potential.

(12) End terminated or wrap around elements

are those elements which have electrical connections on the ends

(sides) and/or bottom of their bodies.

(13) Foreign material

is defined as any material that is foreign to the microcircuit of any non-foreign material that is

displaced from its original or intended position within the microcircuit package. Conductive foreign material is

defined as any substance that appears opaque under those conditions of lighting and magnification used in

routine visual inspection. Particles shall be considered embedded in glassivation when there is evidence of

color fringing around the periphery of the particle.

(14) Glassivation

is the top layer(s) of transparent insulating material that covers the active area including

metallization, except bonding pads and beam leads. Crazing is the presence of minute cracks in the

glassivation.

MIL-STD-883F

METHOD 2017.8

18 June 2004

(15) Insulating layer

is a dielectric layer used to isolate single or multilevel conductive and resistive material or to

protect top level conductive resistive material.

(16) Intermetallics (Purple Plague)

is one of several gold-aluminum compounds formed when bonding gold to

aluminum and activated by re-exposure to moisture and high temperature (>340°C). Purple plague is purplish

in color and is very brittle, potentially leading to time-based failure of the bonds. Its growth is highly enhanced

by the presence of silicon to form ternary compounds.

(17) Mechanical strength tests

are tests, such as Mechanical Shock or Constant Acceleration, which demonstrate

adequate attachment process and materials.

(18) Non-monometallic compound bond

consists of two lead bonds, made of dissimilar metals, which are stacked

one on top of the other (i.e., the interface between the two lead bonds are made up of dissimilar metals such as

an aluminum lead bond stacked on top of a gold lead bond or vice-versa.

(19) Operating metallization (conductors)

is all metal or any other material used for interconnections except

metallized scribe lines, test patterns, unconnected functional circuit elements, unused bonding pads and

identification markings.

(20) Original design separation

is the separation dimension or distance that is intended by design.

(21) Original width

is the width dimension or distance that is intended by design (i.e., original metal width, original

diffusion width, original beam width, etc.).

(22) Passivation

is the silicon oxide, nitride, or other insulating material that is grown or deposited directly on the die

prior to the deposition of the final metal layers.

(23) String

is a filamentary run-out or whisker of polymer material.

(24) Substrate

is the supporting structural material into and/or upon which the passivation, metallization, and circuit

elements are placed.

(25) Tuning

is the adjustment of signals from an RF/Microwave circuit by altering lines or pads; adding, deleting or

manipulating wires/ribbons; and/or changing resistance, inductance or capacitance values to meet specific

electrical specifications.

(26) Through hole metallization

is the metallization that electrically connects the metallization on the top surface of

the substrate to the opposite surface of the substrate.

(27) Unused component or unused deposited element

is one not connected to a circuit or connected to a circuit

path at one and only one point. A connection may be made by design or by visual anomaly.

(28) Void

is any region in the material (interconnects, bonding sites, etc.) where underlying material is visible that is

not caused by a scratch.

(29) Visible line

is defined as 0.5 mil at 60X magnification.

g. Interpretations

. References herein to "that exhibits" shall be considered satisfied when the visual image or visual

appearance of the device under examination indicates a specific condition is present and shall not require

confirmation by any other method of testing. When other methods of test are to be used to confirm that a reject

condition does not exist, they shall be approved by the acquiring activity.

MIL-STD-883F

METHOD 2017.8

18 June 2004

h. Foreign material control

. The manufacturer shall perform an audit on a weekly basis for the presence of foreign

material on the die surface, or within the package. This audit may be satisfied during routine internal visual

inspection. If the presence of any type of foreign material/contamination is discovered, the manufacturer shall

perform the necessary analysis on a sample of suspect devices to determine the nature of the foreign material.

The manufacturer shall then document the results of his investigation and corrective actions to eliminate the

foreign material and shall make this information available to the Government QAR, the acquiring activity, or the

qualifying activity, as required. Corrective action responses shall be obtained within a maximum of ten (10)

working days of discovery. The intent of this procedure is to require investigation and resolution of foreign

material/contamination problems which do not have effective screening or detection methodology, but that could

cause degradation and eventual failure of the device function. Repetitive findings without obvious improvements

require escalation to Director of Manufacturing and Director of Quality Assurance, or their equivalents, to continue

processing.

3.1 Examination

. Internal visual examination as required in 3.1.1 through 3.1.9 shall be conducted on each SAW,

hybrid/multichip microcircuit, or microwave hybrid microcircuit. The magnifications required for each inspection shall be

those identified in the particular test method used (i.e., 2010, 2017, or 2032 of MIL-STD-883 and 2072, 2073 of

MIL-STD-750).

3.1.1 Active and passive elements

. All integrated circuit elements shall be examined in accordance with MIL-STD-883,

method 2010.

Class H

Class K

(Class level B Monolithic) (Class level S Monolithic)

Method 2010; Para. 3.1.1: Metallization defects.

Method 2010; Para. 3.1.2: Diffusion and passivation layer(s) faults.

Method 2010; Para. 3.1.3: Scribing and die defects.

Method 2010; Para. 3.2.5: Foreign material.

Method 2010; Para. 3.1.4: Glassivation defects.

Method 2010; Para 3.1.6: Film resistors defects.

Method 2010; Para. 3.1.7: Laser trimmed film resistor defects.

Transistor and semiconductor diode elements shall be examined in accordance with MIL-STD-883, method 2010

(paragraphs referenced above) or the identified paragraphs of MIL-STD-750, methods 2072 and 2073 as indicated below.

Passive elements (including substrates) shall be examined in accordance with MIL-STD-883, method 2032.

Visual MIL-STD-750 MIL-STD-883

Inspection

Method 2072 Method 2073 Method 2010

Die metallization 4.1.1 4.1.3, 4.1.5 3.1.1

defects

Diffusion and 4.1.2 4.1.2 3.1.2

passivation

layer(s)

Scribing and die 4.1.3 4.1.1, 4.1.4 3.1.3

defects
