CERAMIC CHIP CARRIER BOND STRENGTH (DESTRUCTIVE PUSH TEST)

1. PURPOSE

. The purpose of this test method is to measure strengths of bonds external to leadless microelectronic

packages (e.g., solder bonds from chip carrier terminals to substrate or wiring board).

2. APPARATUS

. The apparatus for this test method shall consist of suitable equipment for applying the specified stress

to the device terminals. A calibrated measurement and indication of the applied stress in grams force (gf) shall be provided

by equipment capable of measuring stresses up to twice the specified limit value, with an accuracy of ±5 percent or ±0.25 gf,

whichever is the greater tolerance.

3. PROCEDURE

. The test shall be conducted using the following test procedure. All push tests shall be counted and the

specified sampling, acceptance, and added sample provisions shall be observed, as applicable. A minimum of 4 chip

carriers (or use all chip carriers if 4 are not available) on each of a minimum of 2 completed substrates or wiring boards shall

be used. Where there is any adhesive, encapsulant, or other material under, on, or surrounding the chip carrier such as to

increase the apparent bond strength, the bond strength test shall be performed prior to application.

3.1 Test samples

. When packages are bonded to substrates or wiring boards other than those in completed devices, the

following conditions shall apply:

a. The sample of packages for this test shall be taken at random from the same chip carrier population as that used in

the completed devices that they are intended to represent.

b. The packages for this test shall be bonded on the same bonding apparatus as the completed devices, during the

time period within which the completed devices are bonded.

c. The test package substrates shall be processed and handled identically with the completed device substrates,

during the same time period within which the completed device substrates are processed.

3.1.1 Sample preparation

. Substrates must be prepared as follows:

a. A roughly circular area comprising 50 percent, +5 percent, -0 percent of the bonded side of each package to be

tested shall be exposed by either end-mill drilling of the test substrate or other suitable means. If it is not possible

to expose the ceramic in this manner, the packages shall be bonded onto test substrates into which the proper

hole(s) and hole size(s) has (have) been manufactured, providing all other conditions of 3.1 have been met.

b. Suitable support must be provided for the test substrate so that there is a minimum of flexure of the substrate

during the test. This support, if necessary, may be provided by bonding the substrate to a rigid metal plate having

a hole pattern matching that of the test substrate.

c. A cylindrical rigid metal test post must be prepared for each hole size, which will be inserted through the support

plate and test substrate holes. The post will be used to transmit the specified stress from the stress-source

equipment to the exposed package surface. The diameter of the post shall be 85 percent (+5 percent, -0 percent)

of the corresponding test hole diameter. The length of the post shall be sufficient to extend 1 inch (+100 percent,

-0 percent) from the open end of the test hole when the post is inserted completely into the hole.

3.2 Testing

. The test shall be performed in the following manner:

a. A single package shall be pushed during each test sequence.

b. A layer of teflon tape in accordance with MIL-T-27730 or equivalent shall be placed between the exposed chip

carrier surface and the test post prior to testing.

MIL-STD-883F

METHOD 2029

29 May 1987

c. Insert test post into test hole. The contact of the test post to the ceramic chip carrier shall be made without

appreciable impact (<

0.1 inch/minute). With the stressing element of the test equipment traveling at a constant

rate of 0.02 ±1 percent inch/second, apply sufficient force to chip carrier (through test post) to break all chip carrier

to substrate bonds on at least three edges of chip carrier under test. When failure occurs, the force at the time of

failure and the failure category shall be recorded. Any test resulting in the fracturing of either the chip carrier or test

substrate shall be considered unacceptable. The data from the test shall be discarded, and the test performed

again.

3.3 Failure criteria

. Any push test which results in separation with a bond strength of less than 30 kg-force per linear inch

(1180 g-force per linear mm) of solder pad width shall constitute a failure. The bond strength shall be determined by dividing

the separating force by the total of the solder pad widths as measured on the substrate at the package edge, in a direction

parallel to the package edge.

3.3.1 Failure category

. Failure categories are as follows. When specified, the stress required to achieve separation and

the predominant category of separation shall be recorded.

a. Device fracture.

b. Failure in package-bond interface.

c. Terminal break at point not affected by bonding process.

d. Failure in bond-substrate conductor interface.

e. Conductor lifted from board or substrate.

f. Fracture within board or substrate.

4. SUMMARY

. The following details shall be specified in the applicable acquisition document.

a. Minimum bond strength if other than specified in 3.3 or details of required strength distributions if applicable.

b. Sample size number and accept number and selection and number of devices to be tested on each substrate, if

other than 4.

c. Requirement for reporting of separation forces and failure categories, when applicable (see 3.3.1).

MIL-STD-883F

METHOD 2030

29 May 1987

METHOD 2030

ULTRASONIC INSPECTION OF DIE ATTACH

1. PURPOSE

. The purpose of this examination is to nondestructively detect unbonded regions and voids in the die

attach material of semiconductor devices through the measure of acoustic continuity. It establishes methods and criteria for

ultrasonic inspection of semiconductor devices.

a. For certain die attach materials, a dramatic distinction between well-bonded and poorly bonded conditions may be

difficult to achieve. This factor should be considered in relation to the design of each device when application of

this test method is specified.

b. The term "die attach interface" as used in this document refers to the entire area between the silicon die and the

substrate to which it is bonded. This includes the interface between the die attach material and the die, the

interface between the die attach material and the substrate, plus the die attach material itself.

c. The term ultrasonic inspection as used in this document refers to high frequency ultrasonic visualization (imaging)

which produces a gray scale output such as may be provided by ultrasonic scanning (US) or C-SCAN, scanning

laser acoustic microscopy (SLAM), or C-mode scanning acoustic microscopy (C-SAM).

2. APPARATUS

. The apparatus and materials for this test shall include:

a. Ultrasonic imaging equipment with a test frequency sufficient to penetrate to the die attach interface. The test

frequency and focal distance shall be adequate to detect voids as small as 0.0254 mm (0.001 inch) in diameter.

b. Output device: A hard copy grey scale recording unit or other direct recording device (computer storage) shall be

used to produce an image for analysis (manual or automated). The dynamic range of the output image shall be at

least sixteen discernible colors or levels of grey. The image shall be large enough to be viewed at 10X or lower

magnification.

c. Ultrasonic detector: Shall be capable of detecting an acoustic signal which enters the back or bottom of the

package and is reflected by or transmitted through the die attach interface. The reflected mode of imaging shall be

used where the opening of a sealed, hermetic device is undesirable.

3. PROCEDURE

. The ultrasonic generator, receiver, and line scan recorder settings (when used) shall be selected or

adjusted as necessary to obtain satisfactory images and achieve maximum image details within the sensitivity requirements

for the device or defect features the test is directed toward. In the case of reflection mode or transmission mode images,

care must be exercised to insure that the ultrasound penetrates and is sensitive to the entire die attach interface.

3.1 Mounting and views

. The devices shall be mounted in the holding tank so that the devices are not damaged or

contaminated and are in the proper plane as specified. The devices may be mounted in any type of fixture provided the

fixtures do not block the view from the ultrasonic transducer to any portion of the body of the device. The coupling fluid in

the holding tank shall be distilled water or other suitable noncorrosive liquid. The devices shall remain in the coupling fluid

for as short a time as possible. Subsequent to the ultrasound inspection, proper cleaning and drying of the samples are

required.

3.1.1 Views

. All devices, shall have one view made with the acoustic signal penetrating the device in a direction

perpendicular to the plane of the die attach, and for which there is acoustic continuity from the case exterior surface to the

die attach interface (generally, the Y1 direction with the die attach parallel to the XZ plane). For devices with no sealed air

gap above the active surface of the semiconductor element (unlidded devices), a view made with the acoustic signal

directed from or through the active surface of the semiconductor element to the die attach interface may be specified.
